Experimental Investigations on the Influence Factors of Paperboard Deep Drawing

Abstract:

Experiments were conducted to study which type of paperboard and process parameters are suitable for deep drawing of paperboard into trays. The tray is a shallow rectangle box with round corners, wavy bottom and indented walls. Paperboard used in this paper is anisotropic, and its mechanical properties include tensile strength and elongation. Results show that paperboard with the basis weight of 260g/m2 is the suitable type. Proper moisture can improve the tensile strength and ensure the surface quality. Improper blank shape and size can result in wrinkling and cracking.

• Periodical: Applied Mechanics and Materials (Volume 200)
• Pages: 511-515
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.200.511
• Online since: October 2012
• Authors: Ya Jie Li, Zhong Ji, Ren Liu, Yi Guo Luan, Chao Zheng
• Keywords: Deep Drawing, Paperboard, Process Parameter, Rectangle Box, Tray

References

[1] M. Östlund, S. Borodulina and S. Östlund: Technol. Sci, Vol.24 (2011), p.331–341.

[2] M. Hauptmann and J. P. Majschak: Technol. Sci. Vol.24(2011), p.419–432.

[3] H. Huang and M. Nygårds: Nordic Pulp and Paper Research Journal, Vol.24(2010), pp.505-512.

[4] J. Li, F. S. Östlund and C. Fellers: Nordic Pulp and Paper Research Journal, Vol.20(2005) , pp.139-149.

[5] Y. P. E and Z. W. Wang, Packag. Technol. Sci. Vol.23(2010) , pp.471-483.

[6] GB/T 1294-2008: Paper and Board-Determination of Tensile Properties, (China Standards Press, China 2008).
