Electronically Controlled Air Suspension Bus Control System Design

Abstract:

The design of coach electronically controlled air suspension control system was made to be optimized and simplified, especially in hardware. The opto-coupler, inset in the input channels and output channels, let the electric be independent each other between computer system and the external environment and had own reference potential. Interfering signals which maybe make the system not to work by any possibility was suppressed. Practice has proved that reliability, safety and practicality of the control system had been greatly improved.

• Periodical: Applied Mechanics and Materials (Volume 288)
• Pages: 137-141
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.288.137
• Online since: February 2013
• Authors: Fan Wang
• Keywords: Air Suspension, BUS, Conditioning Circuit, Control System, Sensor

References

[1] Ma Youliang editor. Car circuit analysis and fault detection [M] Beijing: Machinery Industry Press, 2006. 2.

[2] Zhao Qiyang. Passenger bus air suspension electronic control system [J]. Bus Technology and Research, 2008 (3): 33 ~ 34.

[3] Chen Jiarui editor. Automobile structure on the books. 2 Version [M] Beijing: Mechanical Industry Press, 2005. 1.

[4] Liu Zhengyu. Electronic circuit design and production [M]. Fuzhou: Fujian Science and Technology Press, 2003. 9.

[5] Qin Zenghuang editor. Electrical engineering. volume two, Electronic version. 6 [M] Beijing: Higher Education Press, 2004. 7.

[6] Song Fuchang. Identification and testing of automotive sensors diagram [M] Beijing: Electronic Industry Press, 2003. 6.

[7] Ma Youliang editor. Automotive electrical and electronic control system. 2 [M] Beijing: Machinery Industry Press, 2006. 12.
