Performance Calculation and Test Analysis of PDM Lining with Super-Elastic Constitutive Model

Abstract:

Based on performance comparison of PDM equidistant and conventional elastomer lining, the impacts on the PDM performance were presented with different equidistant lining thickness. According to the Mooney-Rivlin two-parameter model and the Poisson radio equaling to 0.5, the elastomer is incompressible during the calculation and its relational material parameters such as elastic modulus and shear modulus were determined. The PDM stator and rotor curve equations were established according to hypocycloid theory. The lobe configuration is 3:4, the performance comparisons were investigated including deformation and Mises stress between conventional and equidistant elastomer lining of PDM with contact model. The test data pointed out torque, rotation speed, volumetric and overall efficiency variation results with the motor pressure difference changing from 1.93MPa to 5.90MPa. The presented results could be used for PDM design optimization and performance improvement.

• Periodical: Applied Mechanics and Materials (Volume 307)
• Pages: 139-143
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.307.139
• Online since: February 2013
• Authors: Jia Lin Tian, Rong Ming Hao, Lin Yang, Xin Wang, Zhe Fan, Shan Lin Su, Guo Wei Zhang
• Keywords: Elastomer, Equidistant, Hyperelastic, PDM, Performance Calculation, Test Analysis

References

[1] Li Mingqian, Zhao Hongchao. Failure mechanism and measure analysis of motor stator of screw drill[J], Petroleum Machinery, 2008, 36(10): 8-11.

[2] Thorsten Regener, Matthias Reich, Ralf Duerholt and Bernd Wagner. Latest Positive Displacement Motor and Drill Bit Developments for Drilling Hard and Abrasive Formations, SPE/IADC 92542.

DOI: 10.2118/92542-ms

[3] M. S. Delpassand. Stator Life of a Positive Displacement Downhole Drilling Motor[J]. J. Energy Resour. Technol. June 1999, Volume 121, Issue 2, 110.

DOI: 10.1115/1.2795065

[4] WEI Yintao, YANG Tingqing, DU Xingwen. On the Large Deformation Rubber-like Materials Constitutive Laws and Finite Element Method [J]. Acta Mechanica Solida Sinica, 1999, 20 (4）: 281-289.

[5] Pantuso D, Bathe KJ. On the stability of mixed finite element in large strain analysis of incompressible solids[J]. Finite element analysis and design, 1997, 28: 83~104.

DOI: 10.1016/s0168-874x(97)81953-1

[6] Jialin Tian, Zheng Liang, Lin Yang. Traction transmission gearbox mechanical properties numerical calculation and strength analysis[J]，Advanced Materials Research，Vols. 311-313 (2011): 1411-1416.

DOI: 10.4028/www.scientific.net/amr.311-313.1411
