Influence of Insulating Compounds Addition on Magnetic Properties of FeSi Cores

Abstract:

The process of preparation of Fe-Si cores is studied, and the influence of different amounts of insulating compounds addition on magnetic properties of the cores is discussed. The results show that the effective permeability is 71.4 when the amount of insulation is 0.5 wt%. When the content is increased to 2.5 wt%, the DC Bias characteristic becomes the best. When the insulating compounds addition is 2.5 wt%, the sample has the lowest power loss, which is 308.4 mW/cm³ at f=50 kHz and B=50 mT.

You might also be interested in these eBooks

China Functional Materials Technology and Industry Forum

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 320)

Pages:

7-10

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.320.7

Citation:

Cite this paper

Online since:

May 2013

Authors:

Xiao Hui Zhu, Min Nie, Hai Ming Bai

Keywords:

DC Bias Characteristic, Effective Permeability, FeSi Cores, Insulating Compounds Addition, Power Loss

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] J.Y. Yang, J.S. Wu, and Z.P. Zeng, et al: Investigation on Mechanical Alloying of Fe-Si System [J]. Powder Metallurgy Technology, 1997, 15(3): 165~168 (In Chinese)

Google Scholar

[2] T.J. Zhou, D.H Wang, and J.R Zhang, et al: Microstructure and Magnetic Properties of Fe Si Alloys Prepared by Mechanical Alloying [J]. Acta Physica Siaica，1997, 46(11): 2250-2256

Google Scholar

[3] Q.X. Wang: Study on Mechanical Alloying and Magnetic Properties of Fe-Si System [D]. Wuhan: Wuhan University of Technology, 2002 (In Chinese)

Google Scholar

[4] F. Zheng: Study on Preparation of Fe-Si Magnetic Cores by Mechanical Alloying [D]. Wuhan: Wuhan University of Science and technology, 2006 (In Chinese)

Google Scholar

[5] H. Shokrollahi, K. Janghorban: Effect of warm compaction on the magnetic and electrical properties of Fe-based soft magnetic composites [J]. J Magn Magn Mater, 2007, 313 (1):182-186

DOI: 10.1016/j.jmmm.2006.12.022

Google Scholar

[6] M. Muller, A. Novy, and M. Brunner, et al: Powder Composite Cores of nano-crystalline Soft Magnetic FeSiB-CuNb Alloys [J]. J Magn Magn Mater, 1999, 196: 357-358

DOI: 10.1016/s0304-8853(98)00747-1

Google Scholar

[7] Q.D. Li, F.Z. Lian, and J.H. You, et al: Study on Reducing Loss of Fe-Si-Al soft Magnetic Powder Cores [J]. Journal of Northeastern University (Natural Science), 2009, 30(6):837-840

Google Scholar
