The Effect of the Toe on the Biped Robot

Abstract:

Evaluation of 9-DOF biped robots based on designated smooth and stable trajectories with two added toes is a challenging problem that is the focus of this paper. Simultaneously rotation of feet and toes is considered, which allows the robot to walk more efficiently and like a human being. A desired trajectory for the lower body is designed to increase the stability margin. This obtained by fitting proper polynomials at appropriate break points. Then, the upper body motion is planned based on the Zero Moment Point (ZMP) criterion to provide a stable motion for the biped robot. Next, dynamics equations are obtained for both single support phase (SSP) and double support phase (DSP). On the other hand, two biped robots, which one accompanied by toes, are also compared. Simulation results reveal that the biped robots with toes have better stability margin, less power consumption and more vertical reaction force.

• Periodical: Applied Mechanics and Materials (Volumes 325-326)
• Pages: 1076-1082
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.325-326.1076
• Online since: June 2013
• Authors: Seyed Mehdi Torklarki, Mohammad Danesh
• Keywords: Biped Robots, Gait Planning, Stability, Trajectory

References

[1] T. McGeer, "Passive walking with knees," in Proc. IEEE Int. Conf. Robotics and Automation, 1990, p.1640–1645.

[2] P. H. Channon, S. H. Hopkins, and D. T. Phan, "Derivation of optimal walking motions for a biped walking robot," Robotica, vol. 10, no. 2, p.165–172, 1992.

DOI: 10.1017/s026357470000758x

[3] M. Rostami and G. Bessonnet, "Impact less sagittal gait of a biped robot during the single support phase," in Proc. IEEE Int. Conf. Robotics and Automation, 1998, p.1385–1391.

DOI: 10.1109/robot.1998.677298

[4] L. Roussel, C. Canudas-de-Wit, and A. Goswami, "Generation of energy optimal complete gait cycles for biped robots," in Proc. IEEE Int. Conf. Robotics and Automation, 1998, p.2036–2041.

DOI: 10.1109/robot.1998.680615

[5] F. M. Silva and J. A. T. Machado, "Energy analysis during biped walking," in Proc. IEEE Int. Conf. Robotics and Automation, 1999, p.59–64.

[6] M. Vukobratovic, B. Brovac, "Zero-Moment Point-Thirty five years of its life," Int. Journal of Humanoid Robotics, Vol.1, No. 1, pages 157-173,2004.

DOI: 10.1142/s0219843604000083

[7] M. Vukobratovic et al, "Biped Locomotion Dynamic", Stability Control and Application, springer-verlag 1990.

[8] H. K. Lum, M.Zribi and Y. C. Soh, "Planing and Control of a Biped Robot", Int. Journal of Engineering Science, Vol.37, pp.1319-1349, 1999.

DOI: 10.1016/s0020-7225(98)00118-9

[9] K. FUJIWARA et al, "Falling Motion Control to Minimize Damage to Biped Humanoid Robot". Conference on Intelligent Robots and Systems EPFL, Lausanne, Switzerland, (2002)

DOI: 10.1109/irds.2002.1041648
