Study of Two Synchronization Mechanisms for Power Electronic Building Blocks Distributed Digital Control Network

Abstract:

An important development trend toward power electronic technology was the integration and modularization. A key concept was Power Electronic Building Blocks (PEBB). Converters which were PEBB-based had lots of advantages, such as cost reduced, easy to reconfigure, reliability enhanced and so on. PEBB-based converters wound operation with distributed digital control, and a cascaded ring topology was the dominant solution for communication network. The characteristics of the ring topology determined the synchronization mechanism was a key technology. This paper addressed two synchronization mechanisms for ring topology network, and analyzed the factors which impact the synchronization precision. At last, aimed at the practice application, this paper compared their strongpoint with each other.

• Periodical: Applied Mechanics and Materials (Volumes 325-326)
• Pages: 1093-1098
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.325-326.1093
• Online since: June 2013
• Authors: Zhen Xie, Fei Xiao, Chao Bi
• Keywords: Distributed Control, PEBB, Pesnet, Synchronization

References

[1] H. Ginn, F. Ponci, and A. Monti. Multi-Agent Control of PEBB Based Power Electronic Systems[J]. PowerTech, Trondheim, Norway, Jun. 19–23, 2011: 1-6.

DOI: 10.1109/ptc.2011.6019443

[2] Terry Ericsen, Yuri Khersonsky, Peter K. Sterimer. PEBB concept applications in high power electronics converters[C]. IEEE PESC, Sep, 2005: 2284-2289.

DOI: 10.1109/pesc.2005.1581950

[3] Antonello Monti, Ferdinanda Ponci. PEBB standardization as key enabler for power control flexibility[C]. IEEE ISIE, Bari, Italy, Jul. 4–7, 2010: 3695-3699.

DOI: 10.1109/isie.2010.5637746

[4] I. Milosavljevic, Z. Ye, D. Boroyevich, and C. Holton. Analysis of converter operation with phase-leg control in daisy-chained or ring-type structure[C]. Power Electronics Specialists Conference, 1999. PESC 99. 30th Annual IEEE, vol. 2, 27 June- July 1999: 1216-1221．

DOI: 10.1109/pesc.1999.785667

[5] I. Celanovic, N. Celanovic, I. Milosavljevic, D. Boroyev ich, and R. Cooley. A new control architecture for future distributed power electronics systems[C]. Power Electronics Specialists Conference, 2000. PESC 00.2000 IEEE 31st Annual, vol.1 , 18-23 June 2000: 113-118．

DOI: 10.1109/pesc.2000.878817

[6] IEEE 1588 Standard for a Precision Clock Synchronization Protocol for Networked Measurement and Control Systems, http ://ieeeI588.nist.gov/.

DOI: 10.6028/nist.ir.7070

[7] T. Laakkonen, J. Luukko, J. Ahola, P. Silventoinen. Analysis of time-stamping-based synchronization of a PEBB system[C]. IEEE International Symposium on Industrial Electronics Conference, July 5-8, Seoul Olympic Parkel, Seoul, Korea, 2009: 12-17.

DOI: 10.1109/isie.2009.5215658
