The CFD Simulation Analysis on Flow Field of Array Ultrasonic Atomizing Nozzle Coating System

Abstract:

This study aims at the array ultrasonic nozzle sprayed atomization flow field on flat plate, and uses different design and operating parameter combinations to analyze the distribution of spray flow field, the analytic results can be used to improve the flat plate coating performance of the array ultrasonic nozzle spraying equipment. The simulation analysis results will be compared and validated by practical spray coating experiment, so as to determine the reliability of simulation to implement the spray flow field simulation technique for large area uniform spray coating. The mean error value is less than 24%, proving that the simulation results have certain feasibility and accuracy.

• Periodical: Applied Mechanics and Materials (Volume 328)
• Pages: 1000-1003
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.328.1000
• Online since: June 2013
• Authors: Yu Lieh Wu, Szo Tso Li, Wang Lin Liu, Pei Kun Lin
• Keywords: Array Ultrasonic Nozzle, Atomization Flow Field, Numerical Simulation Analysis, Optimum Process Parameters, Spray Coating

References

[1] Lefebvre, A. H., Airblast Atomization, Prog. Energy Combustion Sci., Vol. 6, 1980, p.233. Faeth, G. M., Current Status of Droplet and Liquid Combustion, Prog. Energy Combustion Sci., Vol. 3, 1977, p.191.

DOI: 10.1016/0360-1285(77)90012-0

[2] Sallam, K. A., Dai, Z., and Faeth, G. M., Liquid Breakup at the Surface of Turbulent Round Liquid Jets, International Journal of Multiphase Flow, Vol. 28, 2002, pp.427-779.

DOI: 10.1016/s0301-9322(01)00067-2

[3] Sterling, A. H., and Sleicher, C. A., The Instability of Capillary Jets, Journal of Fluid Mechanics, Vol. 68, 1975, p.477.

DOI: 10.1017/s0022112075001772

[4] Reitz, R. D., and Bracco, F. V., Mechanism of Atomization of a Liquid Jet, Phys. Fluid, Vol. 25, 1982, p.1730.

[5] Lin, S. P., and Kang, D. J., Atomization of a Liquid Jet, Phys. Fluid, Vol. 30, 1987, p.2000.
