Modal Analysis and Design of Six Dimensional Vibration Damping Device Based on Hexapod Platform

Abstract:

A six dimensional vibration damping device is introduced which is composed of Hexapod parallel mechanism and six controllable damp units fixed on driving pairs. Firstly, the structure of the system is designed according to theory of the Hexapod mechanism. Then, Jacobian matrix and dynamics model are discussed successively. Lastly, a six dimensional vibration model is found by using ADAMS software. Through theory and simulation analysis, it has been approved that the system can be used to control six dimensional vibrations.

• Periodical: Applied Mechanics and Materials (Volume 33)
• Pages: 128-131
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.33.128
• Online since: October 2010
• Authors: Wei Zhu, De Jun Kong, Ai Ping Hu
• Keywords: Hexapod Platform, Modal Analysis, Natural Frequency

References

[1] Li C: Earthquake Engineering & Structural Dynamics Vol. 29(2000) No. 9, pp.1405-1421.

[2] G.X. Ren, Q.H. Lu and N. Hu: On Vibration Control with Stewart Parallel Mechanism, Mechatronics Vol. 14 (2004), pp.1-13.

[3] D. Stewart: Institution of Mechanical Engineers Vol. 180(1965) M, 371-386.

[4] L.Z. Ma, X.Q. Yin: Chinese Journal of Mechanical Engineering, Vol. 40 No. 1, Jan., 2004, 21-24.

[5] Z. Jason Geng, S. H: Leonard aynes. Six Degree-of-Freedom Active Vibration Control Using the Steward Platform [J]. IEEE, 1994, 2(1): 45-53.
