Finite Element Analysis of the Frame of Straightening Machine with Twelve Rolls for Tubes

Abstract:

The frame of a straightening machine is a body of the equipment, and bears all loads exerting on the machine. It is necessary for the frame to have strong strength and stiffness so that the machine can work under normal condition. What is more, because control technology for a hydraulic or servo system is applied to this equipment, it is also necessary to understand the variation laws of frame under loads, so that the effects of pressure protection and position control of rollers could be better and the laws could be provided for designing control system. In this paper, the deformation maps of the frame under loads are got by finite element analysis, distribution laws on stress and displacement of the frame are obtained when it is working, and suggestions are proposed for improving the functions of frame and quality of tubes.

• Periodical: Applied Mechanics and Materials (Volume 345)
• Pages: 557-560
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.345.557
• Online since: August 2013
• Authors: Bai Sen Zhang, Jin Chun Song, Guang An Ren
• Keywords: Deformation, Finite Element, Frame, Hydraulic, Straightening Machine, Tubes

References

[1] Qibing Zhang. Study on the strength and stiffness of mill housing [J]. Heavy Machinery. 2003, 5: 13-16.

[2] Jingwei Piao. FEM Analysis and Study on Bow Frame Intensity and Rigidity of Cross-Roll Straightene [D]. Anshan, University of Science and Technology, 2008. 3. 25.

[3] Yunhe Zhao, Jingxun Ma, Taohong Liao, Weichun Shan. Stressing Analysis of Hot Leveler Framework [J]. Shandong Metallurgy, 2006, 28(3): 59-61.

[4] Hong Liu. Strength Analysis on φ550 Straightening Machine [J]. Gansu Metallurgy, 1995, (4): 1-7.

[5] Pingke Zhao, Shusheng Liu, Jinlan Bai, Cunlong Zhao. FEM Analysis of Closed Frame Welded by Plate [J]. Mechanical Engineering and Automation, 2007, (5): 7-11.

[6] Xiaojin Liu, Xiaoming Yang, Delin Zhang, Jingtian Zhang, Yi Liu, Riqing Wang. Finite Element Analysis for Framework of the Wide Heavy Plate Leveling Machine [J]. Mechanical Engineering and Automation, 2006, (4): 28-30.

[7] John R S. Modern straightening machine for pipe, tube, bars and sections [J]， Iron and Steel Engineer, 1977, (11)：38-45.

[8] Mischke, J. Jonca. Simulation of the roller straightening processes [J]， Journal of M- aterials Processing Technology, 1992, (34)：265 – 272.

[9] E Doege，R Menz，et a1．Analysis of Leveling Process Based Upon an Analytic Forming Model[J]，Annals of the ClRP，2002，51(1).
