Harmonic Instability at Sending End of the Exceedingly Weak HVDC System

Abstract:

As the development of high voltage direct current (HVDC) transmission, the problems of harmonic instability become more prevalent. Besides, harmonic instability in exceedingly weak HVDC systems is particularly serious. The modulation of the DC converter based on switching function is deduced. By considering the whole process of harmonic transferring at the AC and DC side through converters from the perspective of circuit, the generation conditions of harmonic instability are analyzed. Then an exceedingly weak HVDC system model is established and simulated in PSCAD/EMTDC software to verify the theoretical analysis. The study results provide theoretical basis and computational methods to solve the problems of harmonic instability in HVDC systems.

• Periodical: Applied Mechanics and Materials (Volumes 347-350)
• Pages: 1343-1347
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.347-350.1343
• Online since: August 2013
• Authors: Wen Jia Cao, Jun Wen, Shu Qing Ma, Jun Ru Xue, Hai Ning Zhang, Si Yu Zhou, Si Zhuo Lv
• Keywords: Exceedingly Weak HVDC Systems, Harmonic Instability, PSCAD/EMTDC, Switching Function

References

[1] FAN Lijuan, MU Zilong, JIN Xiaoming, WANG Yuhong and LI Xingyuan, Criterion of Harmonic Instability at Sending End of HVDC Power Transmission System, Automation of Electric Power Systems, Vol. 36, No. 4, 2012, pp.62-68.

[2] MU Zilong and LI Xingyuan, Harmonic Instability Caused by Interactions Between AC and DC Transmission Systems, Automation of Electric Power Systems, Vol. 33, No. 2, 2009, pp.96-100.

[3] L. Hu and R. Yacamini, Harmonic Transfer Through Converter and HNDC Links, IEEE Trans on Power Electronics, Vol. 7, No. 3, 1992, pp.514-525.

DOI: 10.1109/63.145139

[4] L. Hu and R. Yacamini, Calculation of Harmonic Interference in HVDC Systems with Unbalance, Proceedings of IEE Fourth International Conference on AC and DC Power Transmission, 17-20 September 1991, pp.390-394.

[5] L. Hu and R. E. Morrison, The Use of Modulation Theory to Calculate the Harmonic Distortion in HVDC Systems Operating on an Unbalanced Supply, IEEE Trans on Power Electronics, Vol. 12, No. 2, 1997, pp.973-980.

DOI: 10.1109/59.589796

[6] LIANG Jiyun, Harmonic Analysis in High Voltage Direct Current Transmission System, Master Degree. Thesis, Southwest Jiaotong University, Chengdu, (2012).

[7] WANG Yuhui, HAO Wei and LI Xingyuan, Research on Harmonic Instability Caused by HVDC Converter, Modern Electric Power, Vol. 26, No. 4, 2009, pp.26-30.

[8] HUANG Heyan, WANG Gang, LI Haifeng and LI Zhikeng, The Impedance Frequency Characteristics Analysis of800kV UHVDC Transmission Converter, The Twenty-fourth Annual Conference of Chinese Institutions on Electrical Engineering and Its Automation, Beijing, 24-27 October 2008, pp.691-694.

[9] LI Gengyin, LV Pengfei and Li Guangkai, Development and Prospects for HVDC Light, Automation of Electric Power Systems, Vol. 27, No. 4, 2003, pp.77-81.
