Development and Implementation of a Novel Digital Shot Sensor System

Abstract:

Kinetic information acquisition of shot throwing is significant for the train of shot put athletes. This paper presents a novel sensor system based on a 9 degrees of freedom inertial measurement unit, which provides attitude information of shot throwing in real time. The sensor system is designed with modularized structure and installed in the digital shot which has almost the same size and weight as the standard shot for females. A multi-target and multi-parameter information acquisition platform is constructed to acquire kinematics information. With the help of the sensor system, the coaches can combine attitude information with kinematics data to analyze the shot throwing movements.

• Periodical: Applied Mechanics and Materials (Volume 364)
• Pages: 228-232
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.364.228
• Online since: August 2013
• Authors: Wei Tian Wang, Quan Jun Song, Yu Man Nie, Bu Yun Wang, Hong Yu Ren, Yun Jian Ge
• Keywords: Attitude Information, Digital Shot, Inertial Measurement Unit, Sensor System
