In Situ Measurement of Elastic Modulus of Individual Layers for Composite Thin Films by MEMS Test Structures

Abstract:

In this paper, a direct and simple method to characterize the elastic modulus of individual layers for composite films by in situ measuring of MEMS test structures is presented. The structure is composed of a set of microactuators which contains a rigid plate with two supporting composite beams. A model is developed to describe analytically the relationship between the force and the deflection of microactuators by electrostatic measurements, and the elastic modulus of multi-layered beams with different widths are evaluated. FEM simulations are implemented to validate the accuracy of the relationship between the on-load voltage and the capacitance between the microactuator and the electrode on the substrate. Test structures are fabricated using CMOS-MEMS process and experiments are to be carried out soon.

• Periodical: Applied Mechanics and Materials (Volume 364)
• Pages: 248-252
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.364.248
• Online since: August 2013
• Authors: Chao Sun, Zai Fa Zhou, Wei Hua Li, Qing An Huang
• Keywords: Composite Thin Films, Elastic Modulus, In Situ Measurement, MEMS, Test Structures

References

[1] H. A. C. Tilmans, M. Elwenspoek, and J. H. J. Fluitman: Sens. Actuators, A Vol. 35 (1992), pp.35-53.

[2] U. Harms, L. Kempen, and H. Neuhäuser: Thin Solid Films Vol. 323 (1998), pp.153-157.

[3] S. D. Senturia: Proc. IEEE Vol. 86 (1998), pp.1611-1626.

[4] K.E. Petersen: IEEE Trans. Electron Devices Vol. 25 (1978), pp.1241-1249.

[5] C. L. Dai: J. Micromech. Microeng. Vol. 13 (2003), pp.563-567.

[6] G. M. Rebeiz: RF MEMS Theory, Design, and Technology, (John Wiley & Sons, 2003).

[7] J. M. Gere, B. J. Goodno: Mechanics of Materials, (Cengage Learning, Canada 2009).
