X-Ray Measurement for Residual Stress in Cold Ring Rolling

Abstract:

The residual stress in cold rolling could decrease the accuracy of ring parts. Because many factors could cause residual stress, it’s difficult to calculate it theoretically. At present, a measurement method was generally used to study the residual stress. For example, X ray could be used to measure residual stress in rings. Through the measurement of residual stress, it could not only obtain the residual stress level after ring rolling, but also validate the finite element model to predict the residual stress distribution. However, because the ring surface was circle, it needs to cut a plane for X ray measure, and it increases measurement inaccuracy. This method only could be suited for qualitative analysis of residual stress in cold ring rolling, and it is not suitable for quantitative analysis of residual stress distribution.

• Periodical: Applied Mechanics and Materials (Volumes 37-38)
• Pages: 1647-1650
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.37-38.1647
• Online since: November 2010
• Authors: Z.J. Zuo, Wu Xin Yu, Jun Jie Yang
• Keywords: Cold Ring Rolling, Finite Element, Residual Stress, X-Ray Measurement

References

[1] H. L. Yu and X. H. Liu: Hot Working Technology, Vol. 36 (2007) No. 1, pp.1-3. (in Chinese).

[2] H. Lin, Z. J. Zuo, J. Lan and D. S. Qian: Chinese Journal of Mechanical Engineering, Vol. 44 (2008) No. 10, pp.201-205. (in Chinese).

[3] L. Y. Li, H. Yang and L. G. Guo: Mechanical Science and Technology, Vol. 24, (2005), No. 7, pp.808-811. (in Chinese).

[4] Y. A. Chen and S. Q. Zhou: Nonde Structive Testing, Vol. 23, (2001)No. 1, pp.19-22. (in Chinese).

[5] D. Q. Zhang: Physical Testing and Chemical Analysis (Part A: Physical Testing), Vol. 42. (2007), No. 5, pp.263-265. (in Chinese).

[6] Z. J. Zuo and Y. Li: Hot Working Technology, Vol. 38 (2007) No. 6, pp.21-28. (in Chinese).
