Design of a High Power Programmable Intelligent Switch

Abstract:

Based on the need to develop and test the products, a single phase DSP­based programmable AC power supply is designed. The power supply is capable of providing a stable AC voltage with adjustable amplitude and frequency over a wide range. Moreover, it can generate various high quality and low frequency arbitrary waveforms. Because of the advantages above, it will have great value in practice and a promising future in testing field. The main circuit of the power supply is to use rectifier and filter to make 220V AC voltage become steady DC voltage firstly. Then the inverter and the LC LPF are employed to produce the AC voltage which is required in the test system. The key part of the inverter is phase shift full bridge.

• Periodical: Applied Mechanics and Materials (Volume 389)
• Pages: 421-424
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.389.421
• Online since: August 2013
• Authors: Bai Fen Liu, Ying Gao
• Keywords: Digital Control, Duty Cycle Loss, Parasitic Oscillation, Phase Shift Full Bridge Converter, Zero Voltage Switching (ZVS)

References

[1] Jung-Goo Cho, Sabate.J. A, Guichao Hua, et, al. Zero-voltage and zero-current-switching full bridge PWM converter for high-power application. IEEE Transactions. On Power Electronics, 1996, 11(4): 622-628.

DOI: 10.1109/63.506128

[2] E. S. Kim, K. Y. Joe,M. H. Kye, et, al. An improved soft-switching PWM FB DC/DC converter for reducing conduction losses. IEEE. Trans. Power Electron, vol. 14, No. 2, 1999, pp: 258-264.

DOI: 10.1109/63.750178

[3] Jong-kyu Jung, Woo-seub Youm, Kyi-hwan Park, Vibration reduction control of a voice coil motor (VCM) nano scanner, International Journal of Precision Engineering and Manufacturing, vol. 10, no. 3, pp.167-170, (2009).

DOI: 10.1007/s12541-009-0063-7

[4] Chien-Sheng Liu, Psang-Dain Lin, Po-Heng Lin, Shun-Sheng Ke, Yu-Hsiu Chang and Ji-Bin Horng, Desing and characterization of miniature auto-focusing voice coil motor actuator for cell phone camera applications, IEEE Transactions on Magnetics, vol. 45, no. 1, pp.155-159, June (2009).

DOI: 10.1109/tmag.2008.2006564

[5] Shir-Kuan Lin, Chao-Min Wang and Shyh-Jier Wang, Design and implementation of anti hand shaking position control for a voice coil motor, Journal of Applied Physics, vol. 103, no. 7, pp. 07F128, (2008).

DOI: 10.1063/1.2839338

[6] Xinbo. Ruan, Fuxin Liu. An improved ZVS PWM full-bridge converter with clamping diodes. Power Electronics Specialists Conference, 2004. PESC 04. 2004 IEEE 35th Annual Vol. 2, 2004, pp: 1476-1481.

DOI: 10.1109/pesc.2004.1355642
