The Design and Analysis of the Actuator with Long Stroke and Micro-Displacement

Abstract:

In this paper, a new actuator with nanoscale micro-displacement is reported. The actuator not only can achieve a large stroke and nanoscale positioning accuracy, but also has the advantages of compact, low cost, high reliability and a single control system. The drive is controlled by a single power, and it consists of stepper motor, harmonic gear reducer, screw and the guide rail. The stepper motor is controlled by the pulse train and the harmonic gear reducer has high precision and small hysteresis. The precision screw converts the rotary motion of the stepper motor into linear displacement, and the plunger pushes the target in nanoscale motion accuracy through the guide rail finally.

• Periodical: Applied Mechanics and Materials (Volume 389)
• Pages: 668-674
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.389.668
• Online since: August 2013
• Authors: Ge Pan, Ya Nan Zhang, Lin Zhi Sun, Lin Yong Shen, Cheng Gang Wang
• Keywords: Actuator, Mechanical Transmission, Nanopositioning, Precision Analysis

References

[1] Liu Dengyun, Yang Zhigang, Zeng Ping. The status and trends of the micro-displacement mechanism. Mechanical design and manufacturing. Vol. 1 (2007), pp.156-158.

[2] Zhang Yanan, Su Jianliang, et al. The design of strong laser multi-dimensional target ball precision focusing system, Journal of Scientific Instrument. Vol. 20 (1999), pp.64-67.

[3] J. Qiao, A. Kalb, M. J. Guardalben, G. King, D. Canning, and J. H. Kelly. Large-aperture grating tiling by interferometry for petawatt chirped-pulse–amplification systems. Optical Society of America, (2007).

DOI: 10.1364/oe.15.009562

[4] Qiao J, Kalb A, Nguyen T, et al. Demonstration of laser-aperture tiled-grating compressors for high-energy petawatt lass, chirped-pulse amplification systems Optics Letters. Vol. 33 (2008), pp.1684-1686.

DOI: 10.1364/ol.33.001684

[5] N Blanchot, G Behar, T Berthier, E Bignon et al. Overview of PETAL, the multi-Petawatt project on the LIL facility. IOP science. (2008).

[6] Information on http: /www. Newport. com/ the VACUUM and ultrahigh Vacuum Picomotor Actuators.

[7] Sun Lin zhi, Li Mingming, Cheng Weiming. The design of precision positioning technology. Optics and Precision Engineering, Vol. 13 (2005), pp.69-75.

[8] Long Fei. Analysis for structure and moving precision of large-caliber grating tiling device. The master's thesis of Harbin Institute of Technology, (2011), pp.9-15.

[9] Xi Ping Chen, Yan Min Xiao, Kun Lv. Design and Research of Micro-Displacement Amplifier Driven by Piezoelectric Actuator Advanced Materials Research. Vol. 308-310 (2011), pp.284-287.

DOI: 10.4028/www.scientific.net/amr.308-310.284
