Neural Network Approach to Gain Scheduling for Traction Control of Electrical Vehicles

Abstract:

This paper proposes a gain scheduling approach by neural network to force control of the electric vehicle wheels. To approximate to the reality in simulation, we utilize the traction force database of the motor, called the current-RPM-torque database, instead of the slip ratio measurements. The system is nonlinear and a constant gain cannot overcome all road conditions of the traction force control for the electric vehicles. The appropriate gains for different road conditions can be the training data of the neural network. In this paper, the proper parameters for the RBF neural network are obtained. The appropriate gains which have to fit the assigned specifications in time domain seem to be inverse proportion to the slip ratio slope.

• Periodical: Applied Mechanics and Materials (Volume 392)
• Pages: 272-276
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.392.272
• Online since: September 2013
• Authors: Jieh Shian Young, Yi Pin Lin, Po Wen Shih
• Keywords: Electric Vehicle (EV), Neural Network (NN), Slip Ratio, Traction Force Control

References

[1] Y. Hori, Y. Toyoda, and Y. Tsuruoka, Traction control of electric vehicle: basic experimental results using the test EV UOT electric march, IEEE Transactions on Industry Applications, vol. 34, pp.1131-1138, (1998).

DOI: 10.1109/28.720454

[2] J. -S. Young and S. -Y. Wu, A feasible approach to the evaluation of the tractions of vehicle wheels driven by DC motors., in The International Multi-Conference on Complexity, Informatics and Cybernetics, (2010).

[3] Y. Hori, Future vehicle driven by electricity and control - Research on four-wheel-motored "UOT Electric March II", IEEE Transactions on Industrial Electronics, vol. 51, pp.954-962, (2004).

DOI: 10.1109/tie.2004.834944

[4] X. Peng, H. Zhe, G. Guifang, X. Gang, C. Binggang, and L. Zengliang, Driving and control of torque for direct-wheel-driven electric vehicle with motors in serial, Expert Systems with Applications, vol. 38, pp.80-86, (2011).

DOI: 10.1016/j.eswa.2010.06.017

[5] F. Borrelli, A. Bemporad, M. Fodor, and D. Hrovat, An MPC/hybrid system approach to traction control, Control Systems Technology, IEEE Transactions on, vol. 14, pp.541-552, (2006).

DOI: 10.1109/tcst.2005.860527

[6] W. Wei-Yen, C. Guan Ming, and C. W. Tao, Stable anti-lock braking system using output-feedback direct adaptive fuzzy neural control, in Systems, Man and Cybernetics, 2003. IEEE International Conference on, 2003, pp.3675-3680 vol. 4.

DOI: 10.1109/icsmc.2003.1244460

[7] H. Lv, Y. Jia, J. Du, and Q. Du, ABS composite control based on optimal slip ratio, in Proceedings of American Control Conference, New York City, USA, 2007, pp.5748-5752.

DOI: 10.1109/acc.2007.4282271

[8] A.K. Baker, Vehicle braking. London: Pentch Press, (1986).

[9] Advantech, USB-4704 User Manual. Taiwan: Advantech Co., Ltd, (2010).
