Research on Power Supply Strategies of Long Stroke Primary Segmented Permanent Magnet Linear Synchronous Motor

Abstract:

Long stroke linear motor has an unparalleled advantage in the field of long-distance transport, transfer and electromagnetic launch system. The paper presents a primary segmented permanent magnet linear synchronous motor (PS-PMLSM), which can solve the problems of the long stroke linear motor in excessive power dissipation, the difficulties of power supply. According to the motor structure characteristics and application background, the paper proposes four feasible strategies--a single inverter series alternating power supply (SISAP), a single inverter parallel alternating power supply (SIPAP), dual inverters alternating power supply (DIAP) and inter-segment optimal power supply (ISOP). Firstly, the article makes studies on those strategies from the economic cost, energy efficiency, the complexity of switching among the segments and the convenience of algorithm application by calculation and simulation. Secondly, the mathematics model of the motor and control system model is deduced from different strategies, respectively. Then, the available control method is derived from the analysis of these models and the motion characteristics. Finally, effects of performance are comparatively analyzed through the simulation.

• Periodical: Applied Mechanics and Materials (Volumes 416-417)
• Pages: 209-214
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.416-417.209
• Online since: September 2013
• Authors: Li Yi Li, He Zhu, Ming Na Ma, C.C. Chan
• Keywords: Power Supply Strategy, PS-PMLSM

References

[1] J.M.M. Rovers, J.W. Jansen and E.A. Lomonova, Novel Force Ripple Reduction Method for a Moving-Magnet Linear Synchronous Motor with a Segmented Stator. Pp. 2942-2947, (2008).

[2] Kenji Suzuki, Yong-Jae Kim. Driving Method of Permanent-Magnet Linear Synchronous Motor with the Stationary Discontinuous Armature for Long-Distance Transportation System, IEEE Transactions on industrial Electronics, VOL. 59, NO. 5, pp.2227-2235, may (2012).

DOI: 10.1109/tie.2011.2148685

[3] Brian M. Perreault, Optimizing Operation of Segmented Stator Linear Synchronous Motors. Proceedings of the IEEE invited paper, Vol. 97, No. 11, pp.1777-1785, Nov (2009).

DOI: 10.1109/jproc.2009.2030234

[4] R. Leidhold, P. Mutschler, Speed Sensorless Control of a Long-Stator Linear Synchronous Motor Arranged in Multiple Segments. IEEE Transactions on Industrial Electronics, Vol. 54, NO. 6, pp.3246-3254. Dec (2007).

DOI: 10.1109/tie.2007.905941

[5] Y. Kim, and H. Dohmeki, Cogging Force Verification by Deforming the Shape of the Outlet Edge at the Armature of a Stationary Discontinuous Armature PM-LSM , IEEE Transactions on Magnetics, Vol. 43, No. 6, , pp.2540-2542, Jun (2007).

DOI: 10.1109/tmag.2007.893297
