Electromagnetic Design of a New Electromagnetic Planetary-Gear Machine

Abstract:

A novel brushless compound-structure permanent-magnet synchronous machine (CS-PMSM) based on the magnetic field modulation principle is proposed for hybrid electric vehicles. As the key part of the brushless CS-PMSM, the operation principle of the electromagnetic planetary-gear machine (EPGM) is investigated by analytical method. The magnetic-field distribution and torque performance of the EPGM are studied by finite-element method (FEM). To obtain the optimal design scheme, the influence of the span ratio and thickness of the magnetic block and the slot-opening on the electromagnetic performance is investigated. Finally, the core loss distribution of the EPGM is investigated and the performance of this machine is fully evaluated.

• Periodical: Applied Mechanics and Materials (Volumes 416-417)
• Pages: 215-220
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.416-417.215
• Online since: September 2013
• Authors: Ping Zheng, Jin Gang Bai, Cheng De Tong, Yi Sui, Zhi Yi Song
• Keywords: Brushless, Compound-Structure Permanent-Magnet Synchronous Machine (CS-PMSM), Core Loss, Electromagnetic Planetary-Gear Machine (EPGM), Hybrid Electric Vehicle, Magnetic Field Modulation

References

[1] E. Nordlund and S. Eriksson, Test and verification of a four-quadrant transducer for HEV applications, Proceedings of IEEE Vehicle Power and Propulsion Conference, 2005, pp.37-41.

DOI: 10.1109/vppc.2005.1554529

[2] Yong Liu, Chengde Tong, Jingang Bai, etc. Optimization of an 80 kW Radial-Radial Flux Compound-Structure Permanent-Magnet Synchro-nous Machine Used for HEVs, IEEE Trans. Magnetics, vol. 47, no. 10, p.2399–2402, Oct. (2011).

DOI: 10.1109/tmag.2011.2157325

[3] Jinming Liu and Huei Peng, Modeling and Control of a Power-Split Hybrid Vehicle, IEEE Trans. Control Systems Technology, vol. 16, no. 6, p.1242–1251, Nov. (2008).

DOI: 10.1109/tcst.2008.919447

[4] Ping Zheng, Ranran Liu, Peter Thelin, Erik Nordlund and Chandur Sadarangani, Research on the Cooling System of a 4QT Prototype Machine Used for HEV, IEEE Trans. Energy Conversion, vol. 23, no. 1, p.61–67, Mar. (2008).

DOI: 10.1109/tec.2007.914356

[5] Ping Zheng, Jingang Bai, etc. Research on Electromagnetic Performance of a Novel Radial Magnetic- Field-Modulated Brushless Double-Rotor Machine, International Conference on Electrical Machines and Systems 2011. Beijing, China. August 20-23, (2011).

DOI: 10.1109/icems.2011.6073503

[6] Ping Zheng, Jingang Bai, Chengde Tong, etc. Investigation of a Novel Radial Magnetic-Field-Modulated Brushless Double-Rotor Machine Used for HEVs, IEEE Trans. Magnetics, vol. 49, no. 3, p.1231–1241, Mar. (2013).

DOI: 10.1109/tmag.2012.2217347

[7] K. T. Chau, Dong Zhang, J. Z. Jiang, Chunhua Liu and Yuejin Zhang, Design of a Magnetic-Geared Outer-Rotor Permanent-Magnet Brushless Motor for Electric Vehicles, IEEE Trans. on magnetics., vol. 43, no. 6, pp.2504-2506, (2007).

DOI: 10.1109/tmag.2007.893714
