Optimization of BiFeO₃MFIS Capacitors Doped Niobium by Using Taguchi Method

Abstract:

In this study,MFIS (Metal/Ferroelectric/Insulator/Semiconductor) capacitors whose structure is Al/BFO+Nb/HfO₂/p-Si are investigatedby using Taguchi Method. The effects of leakage current, memory window, and signal-to-noise ratio (S/N ratio) are discussed by different process conditions. As a result, the leakage current and memory window indicate the better performance on th same process condition. The better conditions of this MFIS capacitoroccur in rapid thermal annealing (RTA) at 700°C, 5W direct current (DC) power of Nb sputtering and 15 of argon-to-oxygen ratio for laekage current and memory window.Oxygen vacancies were reduced bydoping niobium (Nb) that Nb ions replace ferrum (Fe) ions with RTA at 700°C. The more Nb dopesthe more Nb ions replace Fe ions. Butthe excessive Nb induces to increase the leakage current and reduce the memory widow.

You might also be interested in these eBooks

Quantum, Nano, Micro Technologies and Applied Researches

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 481)

Pages:

141-145

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.481.141

Citation:

Cite this paper

Online since:

December 2013

Authors:

K.C. Lin*, C.H. Ko, M.J. Twu, P.C. Juan, H. Sekiguchi, C.H. Chou

Keywords:

BiFeO₃, Memory Window, MFIS Capacitors, Taguchi Method

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] A.Z. Simoes, R.F. Pianno, E.C. Aguiar,E. Long and J.A. Varela, Effect of Niobium Dopant on Fatigue Characteristics BiFeO3Thin Films Grown on Pt Electrodes, Journal of Alloys and Compounds, Vol. 479, pp.274-279, (2009).

DOI: 10.1016/j.jallcom.2009.01.074

Google Scholar

[2] J. Wang, J.B. Neaton, H. Zheng, V. Nagarajan, S.B. Ogale, B. Liu, D. Viehland, V. Vaithyanathan, D.G. Schlom, U.V. Waghmare, N.A. Spaldin, K.M. Rade, M. Wuttig and R. Ramesh, Epitaxial BiFeO3 Multiferroic Thin Film Heterostructures, Science, Vol. 299, No. 5613, pp.1719-1722, (2003).

DOI: 10.1126/science.1080615

Google Scholar

[3] H. Uchida, R. Ueno, H. Funakubo and S. Koda, Crystal Structure and Ferroelectric Properties of Rare-earth Substituted BiFeO3 Thin Films, Journal of Applied Physics, Vol. 100, pp.014106-9, (2006).

DOI: 10.1063/1.2210167

Google Scholar

[4] F. Z. Huang, X. M. Lu, W. W. Lin, X. M. Wu, Y. Kan and J. S. Zhu, Effect of Nd Dopant on Magnetic and Electric Properties of BiFeO3 Thin Films Prepared by Metal Organic Deposition Method, Applied Physics Letters, Vol. 89, pp.242914-3, (2006).

DOI: 10.1063/1.2404942

Google Scholar

[5] B. F. Yu, M. Y. Li, Z. Q. Hu, L. Pei, D. Y. Guo, X. Z. Zhao and S. X. Dong, Enhanced Multiferroic Properties of The High-valence Pr Doped BiFeO3 Thin Film, Applied Physics Letters, Vol. 93, pp.182909-3, (2008).

DOI: 10.1063/1.3020296

Google Scholar

[6] X. D. Qi, J. Dho, R. Tomov, M. G. Blamire and J. L. M. Driscoll, Greatly Reduced Leakage Current and Conduction Mechanism in Aliovalent-ion-doped BiFeO3, Applied Physics Letters, Vol. 86, pp.062903-3, (2005).

DOI: 10.1063/1.1862336

Google Scholar

[7] H. Naganuma, J. Miura and S. Okamura, Ferroelectric, Electrical and Magnetic Properties of Cr, Mn, Co, Ni, Cu Added Polycrystalline BiFeO3 Films, Applied Physics Letters, Vol. 93, pp.052901-3, (2008).

DOI: 10.1063/1.2965799

Google Scholar

[8] Z. X. Cheng, X. L. Wang, S. X. Dou, H. Kimura and K. Ozawa, Improved Ferroelectric Properties in Multiferroic BiFeO3 Thin Films Through La and Nb Codoping, Physical Review B, Vol. 77, pp.092101-4, (2008).

DOI: 10.1103/physrevb.77.092101

Google Scholar

[9] Pi-chun Juan, Chen-Hao Wang, Electrical characterization of metal-ferroelectric (Mn-substituted BiFeO3) -insulator(HfO2)-semiconductor capacitors for nonvolatile memory applications, Microelectronic Engineering, Vol. 86, pp.1845-1848, (2009).

DOI: 10.1016/j.mee.2009.03.007

Google Scholar
