Development of a Grinding Carriage for an Inner Cooling Grinding in a General Grinding Machine

Abstract:

As inner cooling grinding can break the closure of grinding area and solve practical engineering problems resulting from too high grinding temperature, it can be used to realize the grinding of difficult-to-machine materials, such as Titanium alloy, in a general machine such as M7130. An inner cooling grinding wheel, a grinding carriage and cutting fluid system are the key parts of a inner cooling grinding system, and an inner cooling grinding wheel must be fixed on a plain grinder by a grinding carriage, so this paper mainly studies how to design and manufacture a tooling for an inner cooling grinding wheel, which has simple construction and reliable performance. Grinding experiment shows it can dramatically reduce cutting temperature and effectively avoid grinding burn, thus grinding quality is improved.

• Periodical: Applied Mechanics and Materials (Volume 532)
• Pages: 435-438
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.532.435
• Online since: February 2014
• Authors: Liang Dong Zhang*, Yong Wang, Zhi Rong Li
• Keywords: Difficult-to-Machine, Grinding Burn, Grinding Carriage, Grinding Temperature, Inner Cooling Grinding
