Finite Element Analysis for Static Behaviour of the CNC Turning Machine Spindle

Abstract:

This paper presents a method to investigate the characteristics of a turning high-speed spindle system. The geometric quality of high-precision parts is highly dependent on the performance of the entire machining system,especially by the main spindle behaviour. The machine tool main spindle units is focused on direct driven spindle units for high-speed and high performance cutting. This paper analyzes the static behavior for a turning machine spindle and presents some activities to improve the CAD model for such complex systems. The proposed models take into account the spindle with the detailed bearing system. The analysis was performed during the design activity and was based on Finite Elements Method. Starting from the 3D designed model, using FEM done by means of ANSYS analysis the structure stiffness was evaluated and, by consequence, the influence on the machine tool precision. The aim of this paper is to develop a finite element model of the machine spindle system and to use this method for design optimization. The 3D model was designed using the SolidWorks CAD software. The static analysis was completed by modal, harmonic response and thermal analysis, but their results will be presented in other papers.

• Periodical: Applied Mechanics and Materials (Volume 555)
• Pages: 555-560
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.555.555
• Online since: June 2014
• Authors: Doru Bardac*, Constantin Dogariu
• Keywords: Design, Finite Element Method (FEM), High Speed Machining, Precision, Spindle, Stiffness

References

[1] Jay F. Tu - Nuggets of Mechanical Engineering – Revisit of the Free-Body Diagram Analysis and Force Flow Concept - International Conference on Engineering Education – ICEE 2007 Coimbra, Portugal September 3 – 7, (2007).

[2] C. H. Li, Z. R. Liu, Y. Zhou, Y. C. Ding - Investigation on critical speed and vibration mode of high speed grinder - NOISE & VIBRATION WORLDWIDE, November 2011, pp.47-54.

DOI: 10.1260/0957-4565.42.10.47

[3] Meilin Li, Xiaolong Shen - Critical Speed and Vibration Mode for Double-rotor Spindle System of High Speed Grinder - IEIT Proceedings Vol. 3 (2012) pp.81-85.

DOI: 10.5813/www.ieit-web.org/ijadc/2013.1.1

[4] Lida Zhu, Chunxia Zhu, Tianbiao Yu, Jiashun Shi and Wanshan Wang - Dynamic Analysis and Design of the Spindle-Bearing System in Turn-milling Centre - Proceedings of the IEEE International Conference on Automation and Logistics August 18 - 21, 2007, Jinan, China.

DOI: 10.1109/ical.2007.4338978

[5] Yuzhong Cao - Modeling of high-speed machine-tool spindle systems – PhD Thesis, The University of British Columbia, March (2006).

[6] Ṧooṧ L' - Contribution to the research of static and dynamic properties of CNC turning machine - STROJNỈCKY ĈASOPIS, 59, 2008, no. 5–6, pp.231-239.
