Evaluation of Sliding Behavior of Simple Structures for Oblique Collision

Abstract:

When a simple structure collides with inclined barrier, behavior and deformation of the structure after impact are different in the case in which the structure slides on a contact surface or the case in which it does not slide. In order to investigate the structural collapse behavior for oblique collided structure, therefore, it is important to clarify the sliding behavior of the structure on the contact surface. The sliding behavior of the structure during collision was estimated according to theoretically obtained the equation considering the equilibrium of change in the momentum and the impulse before and after the collision. For evaluating the sliding behavior of the simple structure, the impact test by the drop type impact testing machine was carried out to collide with inclined barrier. In the impact test, the circular plate of 60 mm diameter and 10 mm thickness was used as the simple structure, and impacted with various collision velocities (range from 2 to 6 m/s). The sliding behavior of the simple structure at the collided surface was observed by high speed camera, and evaluated by the image analysis. The theoretical result was compared to evaluate with experimental results.

You might also be interested in these eBooks

Proceedings of the 8-th International Symposium on Impact Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 566)

Pages:

611-616

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.566.611

Citation:

Cite this paper

Online since:

June 2014

Authors:

Takeru Watanabe*, Naoya Nishimura, Hiroka Watanabe, Syouta Nakadate, Katsuhiko Murase

Keywords:

Dynamic Friction Coefficient, Impulse-Momentum Equation, Non-Sliding Condition, Sliding Condition, Transition Critical Angle

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] National Police Agency, Occurrence of Traffic Accidents, Portal Site of Official Statics of Japan, February 2013, http: /www. e-stat. go. jp/SG1/estat.

Google Scholar

[2] S. Takezono, H. Minamoto, K. Tao, H, Bitoh: Two-Dimensional Collisions of Vehicles: Case of Vehicles with round Corners, Transactions of the Japan Society of Mechanical Engineer Series C, Vol. 60, No. 569 (1994), p.137.

DOI: 10.1299/kikaic.60.137

Google Scholar

[3] R. Emori: Vehicle Mechanics of Intersection Collision Impact, SAE paper, No. 700177 (1970), p.1.

DOI: 10.4271/700177

Google Scholar

[4] Mizuno, K.: Crash Safety of Passenger Vehicles, The University of Nagoya Press, (2012).

Google Scholar

[5] W. Goldsmith: Impact: The Theory and Physical Behavior of Colliding Solids, (Edward Arnold Publisher, 1960).

Google Scholar
