High-Speed Photogrammetry Application for Percussive Rotary Cutting Tests of Deep-Ocean Cobalt-Rich Crusts

Abstract:

The cutting processes of drill rod under different surge pressures, rotate pressures and propulsion forces were recorded by the high-speed camera in the hydraulic percussive rotary cutting tests of deep-ocean cobalt-rich crusts. Meanwhile, the curves of impact vibration, torsional vibration and frame vibration during the cutting processes were plotted by digital picture processing technique. The impact frequency, torsional vibration frequency, torsional vibration amplitude, vibration amplitude of drill rod and the frame were calculated. The photogrammetry results are generally in agreement with the traditional test results. High-speed photogrammetry is a non-contact, wide range application, and high precision measurement, and the cutting process can be described visually and adequately.

• Periodical: Applied Mechanics and Materials (Volumes 568-570)
• Pages: 1753-1756
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.568-570.1753
• Online since: June 2014
• Authors: Hao Zheng*, Shao Jun Liu, Hai Ren Gan, Ning Yang
• Keywords: High-Speed Camera, Hydraulic Percussive Rotary Cutting, Impact Vibration, Torsional Vibration

References

[1] John E Halkyard. Status of Lift Systems for Polymetallic Nodule Mining [C]. Proceedings of the Workshop on Polymetallic Nodule Mining Technology- Current Status and Challenges Ahead, Chennai, India, 2008：18-22.

[2] The International Seabed Authority (ISA). BACKGROUND DOCU-MENT of Workshop on Polymetallic Nodule Mining Technology- Current Status and Challenges Ahead [C]. Proceedings of the Work-shop on Polymetallic Nodule Mining Technology- Current Status and Challenges Ahead, Chennai, India, 2008(2)：18-22.

DOI: 10.1080/716100481

[3] R. Kotlinski, V. Stoyanova, H. Hamrak, A. Avramov. An overview of the interoceanmetal (IOM) deep-sea technology development (mining and processing) [C]. Proceedings of the Workshop on Polymetallic Nodule Mining Technology- Current Status and Challenges Ahead, Chennai, India, 2008(2)：18-22.

[4] 李军. 液压凿岩机的发展与应用[J]. 有色金属(矿山部分), 2008(3): 36-38.

[5] Napicr Munn T J, Lynch A J. The Modeling and Computer Simulation of Mineral Treatment Process-Current Status and Future Trends[J]. Minerals Engineering, 1992, 5(2): 143-167.

DOI: 10.1016/0892-6875(92)90039-c

[6] Karayel D, Wiesehoff M, Zmerzi A, et al. Laboratory Measurement of Seed Drill Seed Spacing and Velocity of Fall of Seeds Using High-Speed Camera System[J]. Computers and Electronics in Agriculture, 2006, 50(2): 89-96.

DOI: 10.1016/j.compag.2005.05.005
