Nonlinear Interacting System with Neuro-PID Controller

Abstract:

In this paper, a control methodology for nonlinear interacting system is developed, in which the PID controller is implemented by neural networks trained by mean square error (MSE) criterion. The mean square error can be estimated recursively by utilizing receding horizon window technique. The measurable disturbances in nonlinear interacting system are input to the Neuro-PID controller besides the sequences of tracking error and hence the feed-forward control is combined with feedback control in the developed scheme. The applicability of the developed control scheme is demonstrated on Two Conical Tank Interacting Level System (TCTILS) which exhibits dynamic non linearity and coupling dynamics. Simulation results show that the developed control scheme realized a good dynamic behavior of the TCTILS and a perfect level tracking.

• Periodical: Applied Mechanics and Materials (Volume 573)
• Pages: 229-234
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.573.229
• Online since: June 2014
• Authors: V.R. Ravi*, U. Darsana, Thyagarajan T
• Keywords: Neuro-PID, Nonlinear Interacting System, Process Control, Receding Horizon Window Technique

References

[1] Sigeru Omatu, Toru Fujinaka, Michifumi Yoshioka, Neuro-PID Control for Inverted Single and Double Pendulums, IEEE International Conference on Systems, Man & Cybernetics. 4 (2000) 2685 – 2690.

DOI: 10.1109/icsmc.2000.884401

[2] A. Aeenmehr, A. Yazdizadeh, M. S. Ghazizadeh, Neuro-PID Control of an Industrial Furnace Temperature, IEEE Symposium on Industrial Electronics and Applications. 2 (2009) 768 - 772.

DOI: 10.1109/isiea.2009.5356358

[3] Sigeru Omatu, Michifumi Yoshioka, Toshihisa Kosaka, Hidekazu Yanagimoto, Jamal Ahamad Dargham, Neuro-PID Control of Speed and Torque of Electric Vehicle, International Journal on Advances in Systems and Measurements. 3 (2010) 82-91.

[4] Jianhua Zhang, Fenfang Zhang, Mifeng Ren, Guolian Hou, Fang Fang, Cascade control of superheated steam temperature with neuro-PID controller, ISA Transactions. 51 (2012) 778-785.

DOI: 10.1016/j.isatra.2012.06.008

[5] V.R. Ravi, T. Thyagarajan, G. Uma Maheshwaran, Modelling and controlling of two conical tank interacting level system using regime based multi model adaptive concept, International Review on Modelling and Simulations. 6(2) (2013) 639-648.

[6] Tien Dung Le, Hee-Jun Kang, Young-Soo Suh, Young-Shick Ro, An online self-gain tuning method using neural networks for nonlinear PD computed torque controller of a 2-dof parallel manipulator, Advanced Theory and Methodology in intelligent Computing. 116 (2013).

DOI: 10.1016/j.neucom.2012.01.047
