Fiber Optic Sensor for Simultaneous Measurement of pH and Dissolved Oxygen

Abstract:

The work describes the constructions of optical fiber based minimal invasive sensing system to measure pH and dissolved oxygen using sol-gel membranes which are attached internally in any transparent container. The disposable sensing membranes are very thin size and prepared as fluorescent dye doped in silica film using simple procedures. The sensor characteristics such as response time, linearity, repeatability and reversibility are evaluated and the performance of the sensor also compared with commercial meters. The experiments such as, chemical stability and photo stability are also carried out. The detection limit of pH sensor is found between 3 pH and 10 pH, however good sensitivity is obtained for the ranges from 4 pH and 9 pH with the response time of 7 seconds. Non-linear response is obtained for dissolved oxygen sensor and it is made linear by applying Stern-Volmer equation. The oxygen sensor shows good sensitivity in the ranges from 2 mg/L to 8 mg/L.

• Periodical: Applied Mechanics and Materials (Volume 573)
• Pages: 842-847
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.573.842
• Online since: June 2014
• Authors: N. Deepa, A. Balaji Ganesh*
• Keywords: Dissolved Oxygen (DO), Embedded Programming, Fiber Optic Sensor, pH, Simultaneous Measurement

References

[1] Pauline M. Doran, Bioprocess Engineering Principles, Academic Presc Inc, San diego, CA, (1995).

[2] Michael C. Flickinger, Upstream Industrial Biotechnology, 2 Volume Set , John Wiley & Sons Inc, New Jersey, (2013).

[3] John G. Webste, The Measurement, Instrumentation, and Sensors: Handbook, CRC Press LLC, Boca raton, USA, (2000).

[4] John Twork, Sensors in Bioprocess Control, Marcel Dekkar Inc, New York, (1990).

[5] Christophe Piraud, Eustace Mwarania, George Wylangowski, James Wilkinson, Kieran O'Dwyer, David J. Schiffrin , An optoelectrochemical thin-film chlorine sensor employing evanescent fields on planar optical waveguides, Anal Chem , 64 (2000).

DOI: 10.1021/ac00030a015

[6] Wenqing Cao, Yixiang Duan, Optical fiber-based evanescent ammonia sensor, Sensors and Actuators B, 110 (2005) , 252–259.

DOI: 10.1016/j.snb.2005.02.015

[7] Alen Pasic, Hans Koehler, Lukas Schaupp, Thomas R. Pieber, Ingo Klimant, Fiber-optic flow-through sensor for online monitoring of glucose, Analytical and Bio analytical Chemistry, 386 (2006) , 1293-1305.

DOI: 10.1007/s00216-006-0782-x

[8] Shanying Zhu, Youping Chen, Gang Zhang, Jiming Sa, A near-infrared optical fiber sensor for carbon monoxide concentration monitoring , Microwave and Optical Technology Letters, 52 (2010), 2192–2195.

DOI: 10.1002/mop.25469
