Research on Compiled-Type Numerical Control System and its Data Compression Technology

Abstract:

A compiled-type numerical control system based on asynchronous operating mode was proposed. The system constitutes of data center, motion control cards and communication system, solving the contradiction between real-time and openness property. The architecture and work procedure of the system were illustrated. According to the features of system that are large amount of data transmission, high transmission speed requirements and numerous connected devices, data compression technology of NC system was studied. LZW compression algorithm was chosen after contrast, and compression based on PC software was implemented in data center while decompression based on FPGA hardware being implemented in motion control cards. The simulation and experiment results show that data compression ratio could be under 10%, compression and decompression speed are fast and system requirements are satisfied.

• Periodical: Applied Mechanics and Materials (Volume 607)
• Pages: 768-773
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.607.768
• Online since: July 2014
• Authors: Kun Yang Wang*, Ying Xue Yao, Liang Zhou
• Keywords: Compiled, Data Compression, FPGA, LZW Algorithm, Numerical Control System

References

[1] Zhou Kai. PC-based numerical control principle, system and applications [M]. Beijing, China machine press, 2006: 10-20.

[2] Víctor M. Monroy, Juan de Dios Calderón and José C. Miranda V. Taking the Lab into the Classroom: Using Mobile Technology to Monitor and Receive Data from CNC Machines [J]. Journal of Manufacturing Systems, 2005, 24(3): 266-270.

DOI: 10.1016/s0278-6125(06)80017-8

[3] Ren Qing-rong, Chen Ji-hong, Tang Xiao-qi, Zuo Zi-hui. Design and implementation of numerical control system based on Ethernet [J]. Machinery Design ＆ Manufacture, 2009, 9(9): 148-149.

[4] Yan Yang, Zhang Zheng-bing. Introduction to data compression technology [J]. Journal of Yangtze University (Natural Science Edition), 2004, 1(4): 120-121.

[5] Li Lei-ding. Design of real-time lossless compression system based on FPGA [D]. Taiyuan, North University of China, 2009: 2-15.

[6] Xu Xia, Ma Guang-si, Yu Tao. Research and improvement on LZW lossless compression algorithm [J]. Computer technology and development, 2009, 19(4): 125-127.
