Research on the Control of Distributed Power Grid-Connected Inverter

Abstract:

Based on voltage space vector modulation, a distributed power grid-connected inverter (DPGCI) utilizing double loop control strategy is researched, the system is able to feedback power to grid with constant power and unity power factor. the static and dynamic performance is good. Firstly, a mathematical model of inverter system in two-phase synchronous rotating coordinate is built, based on this, a outer power loop and inner current loop control strategy is proposed, realizing the independent control of active and reactive power. Experimental results show the correctness and validity of the control strategy.

• Periodical: Applied Mechanics and Materials (Volume 654)
• Pages: 238-241
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.654.238
• Online since: October 2014
• Authors: Jian Tang, Yue Nan Zeng*, Bin Zhou, Jin Hui Liu
• Keywords: Distributed Power, Grid-Connected, Inverter, Space Vector Modulation

References

[1] Kramer W, Chakraborty S, Kroposki B. Advanced power electronic interfaces for distributed energy systems[M]. Battell: Midwest Research Institute, (2008).

[2] He WANG, Guoqing LI. Control strategy of microgrid with different DG types[J]. Electric Power Automation Equipment, 2012, 32(5): pp.19-23, In Chinese.

[3] MOHAMED Y, SAADANY E. Adaptive decentralized droop controller to preserve power sharing stability of paralleled inverters in distributed generation microgrids[J]. IEEE Trans on Power Electronics, 2008, 23(6): pp.2806-2816.

DOI: 10.1109/tpel.2008.2005100

[4] Frede Blaabjerg, Remus Teodorescu, Marco Liserre, et al. Overview of Control and Grid Synchronization for Distributed Power Genera- tion Systems[J]. IEEE Trans on Industrial Electronics, 2006, 53(5): pp.1398-1409.

DOI: 10.1109/tie.2006.881997

[5] Yong YANG, Yi　 RUAN. Direct power control for three-phase grid-connected inverters[J]. Electric Power Automation Equipment, 2011, 31(9): pp.54-59, In Chinese.

[6] Lei Shang, Dan Sun, Jiabing Hu, et al. Predictive Direct Power Control of Three-Phase Grid-Connected Voltage-Sourced Inverters[J]. TRANSACTIONS OF CHINA ELECTRO　TECHNICAL SOCIETY, 2011, 26(7): pp.216-222 +229, In Chinese.

[7] Jun LI, Yue nan ZENG, Qiang HUANG, et al. Simulation research three-phase PWM Rectifier with Direct Power Control based on Space-Vector Modulation[J]. Computer Simulation, 2012, 29(7): pp.339-342, In Chinese.

[8] Satyaranjan, B. ChittiBabu , Amiya Kumar Naik, et al. Performance Improvement of Single-Phase Grid-Connected PWM Inverter Using PI with Hysteresis Current Controller [J]. IEEE Transactions on Power Electronics, (2011).

DOI: 10.1109/iceas.2011.6147101
