Effect of Fiber Orientation on Vibration Characteristic of Composite Laminated Plates

Abstract:

To describe vibration characteristic of composite laminated plates with various fiber orientations, a composite laminated finite element, which follows classical lamination theory, was constructed. In each ply of rectangular composite laminated plates, the fiber orientation changes with respect to the horizontal coordinate. Natural frequencies and mode shapes of composite laminated plates were studied. The first six natural frequencies and mode shapes of composite laminated plates with various fiber orientations are obtained. The accuracy of this composite laminated element is verified by comparing numerical and theoretical results. The results show that the changes of fiber orientation bring a greater degree of flexibility for structure design of composite laminated plates, which can be used to adjust frequencies and mode shapes of composite laminated plates according to practical engineering need.

• Periodical: Applied Mechanics and Materials (Volumes 670-671)
• Pages: 158-163
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.670-671.158
• Online since: October 2014
• Authors: Hui Fen Peng, Cheng Wang, Peng Wang
• Keywords: Composite Laminated Plates, Fiber Orientation, Natural Frequency, Numerical Model

References

[1] Jegley D, Tating B, Gordal Z. Optimization of elastically tailored tow placed plates with holes[C]. Proceedings of the AIAA/A SCE/AHS/ASC44th, Structures, Structural , Dynamics andMaterials Conference. Norfolk , VA , 2003.

DOI: 10.2514/6.2003-1420

[2] Waldhart C. Analysis of tow-placed, variable-stiffness laminates. MSc Thesis. Blacksburg: Virginia Tech; (1996).

[3] Leissa AW, Martin AF. Vibration and buckling of rectangular composite plates with variable fiber spacing. Compos Struct 1990; 14(4): 339–57.

DOI: 10.1016/0263-8223(90)90014-6

[4] Wu CP, Lee CY. Differential quadrature solution for the free vibration analysis of laminated conical shells with variable stiffness. Int J Mech Sci 2001; 43(8): 1853–69.

DOI: 10.1016/s0020-7403(01)00010-8

[5] DiNardo MT, Lagace PA. Buckling and postbuckling of laminated composites with ply drop-offs. AIAA J 1989; 27(10): 1392–8.

DOI: 10.2514/3.10276

[6] Langley T. Finite element modeling of tow-placed variable-stiffness composite laminates. MSc Thesis. Blacksburg: Virginia Tech; (1999).

[7] Ribeiro P. Forced periodic vibrations of laminated composite plates by a pversion, first order shear deformation, finite element. Compos Sci Technol 2006; 66(11–12): 1844–56.

DOI: 10.1016/j.compscitech.2005.10.007

[8] Qian GL, Hoa SV, Xiao X. A new rectangular plate element for vibration analysis of laminated composites. J Vib Acoust 1998; 120(1): 80–6.

DOI: 10.1115/1.2893830

[9] Jegley D, Tating B, Gordal Z. Tow-steered panels with holes subjected to compression or shear loading[C]. of the AIAA/A SCE/AHS/ASC44th, Structures, Structural , Dynamics and Materials Conference. Austin, TX , 2005: 2005- (2017).

DOI: 10.2514/6.2005-2081

[10] Wang S, Zhang Y. Vibration analysis of rectangular composite laminated plates using layerwise B-spline finite strip method. Compos Struct 2005; 68(3): 349–58.

DOI: 10.1016/j.compstruct.2004.04.001
