Preparation of the Carbon Fiber/Cu Alloy Matrix Self-Lubricating Composite Materials

Abstract:

Using 663-tin bronze, Ni, W, nanoAl₂O₃, MoS₂, graphite, CaF₂, and Ni coated graphite as the matrix alloy powder, in which copper-coated carbon fiber of 5%, 7%, 9%, 11% and 13% in volume fraction were added as the reinforcing phase, a novel type carbon fiber/copper-matrix self-lubricating composite materials was prepared by means of powder metallurgy. The results indicate that the mechanical properties of the composite materials are improved after adding copper-coated carbon fibers. The composite materials reach optimal overall mechanical performance under testing when the volume fraction of the added copper-coated carbon fibers is 11%.: with a hardness of 57.8 HV and a compressive strength of 222 MPa. The addition of carbon fiber also improved the friction and wear properties of the composite materials. Increasing the volume fraction of fiber, was found to increase the wear resistance and improve self-lubricating performance. A volume fraction of 11% gave a friction coefficient of 0.09 and abrasion loss of 4mg.

You might also be interested in these eBooks

Applied Mechanics, Materials and Manufacturing IV

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 670-671)

Pages:

164-167

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.670-671.164

Citation:

Cite this paper

Online since:

October 2014

Authors:

Sui Yuan Chen*, Xin Rong Li, Yu Ning Bi, Daniel Wellburn, Jing Liang, Chang Sheng Liu

Keywords:

Copper-Coated Carbon Fiber, Metal Matrix Composite, Self-Lubrication, Wear

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] L.W. Yang, Y. Dong, R.Y. Wang: Key Engineering Materials Vol. 474-476(201), pp.1605-1610.

Google Scholar

[2] E. Neubauer, M. Kitzmantel, M. Hulman, P. Angerer: Composites Science and Technology Vol. 70(2010), pp.2228-2236.

DOI: 10.1016/j.compscitech.2010.09.003

Google Scholar

[3] J. C . Xu, H. Yu, L. Xia, X.L. Li, H. Yang: Materal Design Vol. 25(2004): p.489–493.

Google Scholar

[4] Y.P. Tang, H.Z. Liu, H.J. Zhao, L. Liu, Y.T. Wu: Materials and Design Vol. 29(2008), pp.257-261.

Google Scholar

[5] W.W. Li, L. Liu, B. Shen: Journal of Composite Materials Vol. 45(2011), pp.2567-2571.

Google Scholar

[6] K. Li, Z.L. Pei, J. Gong, N.L. Shi, C. Sun: Chinese Journal of Space Science 2009; 29(1): 6-9.

Google Scholar

[7] X. Luo, Y.Q. Yang, H.Y. Wang, Y.C. Liu, M. Yuan, Y. Chen: Materials ReviewVol. 20( 2006), pp.76-79.

Google Scholar

[8] S.Y. Chen, J. Wang, Y.J. Liu, J. Liang, C.S. Liu: Journal of Composite Materials Vol. 45(2011), pp.51-63.

Google Scholar

[9] S.Y. Chen, D. An, Y.N. Bi, J. Liang, C.S. Liu: Journal of Composite Materials Vol. 48(2014), pp.1561-1574.

Google Scholar
