Effect of Wall Thickness of Hollow Sphere on the Stress Distribution of Random Hollow Sphere Syntactic Foam

Abstract:

This paper addresses elastic analysis based on 3D finite element model for hollow sphere structures. In finite element models, which were analyzed under pressure of 1MPa, volume fraction of hollow spheres is kept at 30%, and hollow spheres are randomly located in the matrix. Five types of hollow sphere are used to form the model. All the types of hollow spheres have 60μm particle sizes, but different wall thicknesses. A comparison in stress distribution between the hollow sphere and matrix is made, which shows that in composites containing thin-walled hollow particles the maximum stress is located in the inner surface of particle wall, whereas increasing the wall thickness of hollow spheres results in getting some part of matrix around hollow spheres involved in energy absorption. Moreover, the location of the maximum stress in matrix related closely to the spatial arrangement of the particles. The study provides an insight into the micro structural performance of syntactic foam under load.

• Periodical: Applied Mechanics and Materials (Volumes 670-671)
• Pages: 630-633
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.670-671.630
• Online since: October 2014
• Authors: Zhuo Chen, Zhou Zhou, Bing Yan Jiang*
• Keywords: Composite, Microstructure, Particle, Syntactic Foam

References

[1] N. Gupta, E. Woldesenbet, Compos, Hygrothermal studies on syntactic foams and compressive strength determination, Struct. 61 (2003) 311-320.

DOI: 10.1016/s0263-8223(03)00060-6

[2] R. Poveda , N. Gupta, M. Porfiri, Poisson's ratio of hollow particle filled composites, Mater. Lett. 64 (2010) 2360-2362.

DOI: 10.1016/j.matlet.2010.07.063

[3] N. Gupta , E. Woldesenbet, P. Mensah, Compression properties of syntactic foams: effect of cenosphere radius ratio and specimen aspect ratio. Compos. A. 35 (2004) 103-111.

DOI: 10.1016/j.compositesa.2003.08.001

[4] N. Gupta, E. Woldesenbet, Microballoon wall thickness effects on properties of syntactic foams, J. Cell. Plast. 40 (2004) 461-480.

DOI: 10.1177/0021955x04048421

[5] T. Fiedler, HS Kim, I.V. Belova, S.W. Sloan, G.E. Murch, A. Öchsner, Elastic finite element analysis on cross-sections of random hollow sphere structures, Materialwiss. Werkstofftech. 41 (2010) 250-256.

DOI: 10.1002/mawe.201000593

[6] N.Q. Nguyena, N. Gupta, Analyzing the effect of fiber reinforcement on properties of syntactic foams. Mater Sci Eng , Mater. Sci. Eng, A. 527 (2010) 6422-6428.

DOI: 10.1016/j.msea.2010.06.077

[7] P. Louis, A.M. Gokhale, Computer simulation of spatial arrangement and connectivity of particles in 3d microstructure: application to model electrical conductivity of a polymer matrix composite. Acta. Mater. 44 (1996) 1519-1528.

DOI: 10.1016/1359-6454(95)00296-0

[8] Z Chen , ZX Huang , M Zhang , MX Shi , Y Qin , QL Mei, Computer simulation model for spherical particle filled composite materials. Key. Eng. Mater. 474(2011)7-10.

DOI: 10.4028/www.scientific.net/kem.474-476.7
