Analysis of Sealing Properties of Coupled Gas Film Flow Field and Cantilever-Type Foil Deformation

Abstract:

Aimed at cantilever-type foil cylinder film seal system, finite element method analysis model was established to calculate the deformation of cantilever foil under the gas pressure based on the theory of plate bending. The paper proposed a method to solve fluid-solid interaction problems in cantilever-type foil cylinder film seal system based on the numerical analysis method of cylinder gas film seal. The calculation program using the finite element method to solve fluid-solid interaction problems was developed. Calculation simulation of the film mechanical properties and steady-state performance of sealing system was realized which improved the accuracy of the sealing system performance analysis and provided the basis for the multi-parameters matching design of sealing system. The impact of adding cantilever foil support structure to the steady-state performance of sealing system and the influence of flexible support parameters on the steady-state performance of the sealing system was calculated through the method.

• Periodical: Applied Mechanics and Materials (Volumes 670-671)
• Pages: 856-859
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.670-671.856
• Online since: October 2014
• Authors: Gang Ma*, Yun Long Du
• Keywords: Cantilever-Type Foil, Cylinder Gas Film Seal, Flexible Support, Fluid-Solid Interaction, Steady-State Performance

References

[1] Faria M T C: Journal of Tribology Vol. 123(1) (2001), p.205.

[2] Miller B A, Green I: Journal of Tribology Vol. 125(2) (2003), p.403.

[3] Salehi M, Heshmat H: Tribology Transactions Vol. 44(3) (2001), p.458.

[4] Wilbur. Shapiro. Numerical, Analytical, Experimental Study of Fluid Dynamic Forces in Seals[R]. NASA/CR-2004-213199/VOL2, (2004).

[5] Mihai Arghir and Jean Frene: Journal of Tribology. Transaction of the ASME(1997), p.119.

[6] Gang Ma, Xiuhua Li, Xinmin Shen: Journal of Aerospace Power Vol. 26(11)(2012), p.2610. In Chinese.

[7] Guang Zhao, Hechun Yu: Lubrication Engneering Vol. 35(11) (2010), p.115. In Chinese.

[8] Peng Z C, Khonsari M M: Hydrodynamic. Journal of Tribology Vol. 126(3) (2004), p.542.
