The Method and Experimental Research on Seam Tracking and Dual-Beam Laser Welding for T-Type Welding Seam

Abstract:

Aimed at the goal of improving the quality and the efficiency of welding for T-type welding seam, This paper put forward a method to track the seam by using the vision sensor. Machine tool main motion trajectory is generated from the numerical model of the parts. The position of two welding torches are adjusted independently based on the machine tool main motion trajectory to ensure the welding precision. Two sets of adjusting mechanism are needed for T-type welding seam. The vision sensor measure the seam and pass the deviation signal to the CNC system. The CNC system adjust the position of the welding torch installed on the cross slide table to reach the goal of seam tracking and dual-beam laser welding for T-type welding seam. Practice shows that this system for T-type welding seam dual-beam laser welding is easy to operate and can improve the quality and the efficiency.

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 309-315
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.309
• Online since: November 2014
• Authors: Ping Jiang Wang*, Xin Wang, Ling Lin, Yang Wu
• Keywords: CNC System, Dual-Beam Laser, Seam Tracking, T-Type Welding Seam

References

[1] D. Dttrich, J. Standfuss, J. Liebscher et al. Laser beam welding of hard to weld Al alloys for a regional aircraft fuselage design-first results[J]. Phys. Proc. 2011, 12(1): 113~122.

DOI: 10.1016/j.phpro.2011.03.015

[2] X.H. Zhan, J. Chen, Z.B. Dong. Journal of Shenyang University of Technology, 2013. 05, P279-284.

[3] W. Wang, Q.S. Zhou, L.M. Zhu. The Development State and Implementing Method of Seam Tracking System with Optical Sensor. Electric Welding Machine. 2005. 05, 1-8.

[4] Charles Umeagukwn, James McCormick. Investigation of an array technique for robotic seam tracking of weld joints[J]. IEEE Transactions on Industry Electronics，1991, 38(3), 223-29.

DOI: 10.1109/41.87591

[5] J.F. Yu. Ressarch on Deformation Compensation of Motion Trajectory in Three-dimensional Joint Laser Welding. Huazhong University of Science & Technology. 2011. Ressarch on deformation compensation of Motion trajectory in three-dimensional joint laser welding.

[6] Byong-Oh Kam, Yang-Bae Jeon, Sang-Bong Kim. Motion control of two-wheeled welding mobile robote with seam tracking sensor. ISIE，2001: 851~856.

DOI: 10.1109/isie.2001.931579

[7] S.H. Gong, J.F. Yu, J.Z. Yang. Dynamic Compensation for Deformation in Three-dimensional Joint Laser Welding. Transactions of The China Welding Institution. 2013. 02, 89-92.
