Design of Hybrid Ambient Energy Harvesting Antenna for Wireless Sensor Nodes

Abstract:

To the high maintenance cost for changing wireless sensor’s battery in Internet of Things (IoT), a hybrid ambient energy harvesting system for wireless sensor’s power supply is proposed. The system can collect the ambient RF energy, vibration energy and light energy, converts them into DC supply. This paper focuses on the analysis and design of the hybrid energy harvesting antenna, using a novel structure to combine three energy receivers in one antenna, which reduces the size and the cost effectively. The antenna operates at both 3G mobile frequency (1.9GHz) and 4G mobile frequency (2.6GHz), the measured input return loss is 24.3dB and 19.9dB, respectively.

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 3387-3390
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.3387
• Online since: November 2014
• Authors: Lei Jun Xu*, Chang Shuo Wang, Bai Xue
• Keywords: Antenna, Energy Harvesting, Internet of Things (IOT), Wireless Sensor

References

[1] Z. H. Qian, Y. J. Wang. Internet of Things-oriented Wireless Sensor Networks Review, J. Journal of Electronics & Information Technology, 35 (2013) 216-227.

DOI: 10.3724/sp.j.1146.2012.00876

[2] Y. He, P. C. Nie, F. Liu. Advancement and trend of internet of things in agriculture and sensing instrument, J. Transactions of the Chinese Society for Agricultural Machinery, 10 (2013) 216-226.

[3] L. H. Xu, M. H. Zao, R. H. Wei, et al. Adaptive control algorithms of transmitting power for greenhouse WSN nodes, J. Transactions of the Chinese Society of Agricultural Engineering , 30 (2014) 142-148.

[4] Maorais R, Miguel A F, Samuel G M, et al. A ZigBee muti-powered wireless acquisition device for remote sensing applications in precision viticulture, J. Computers and Electronics in Agriculture, 62 (2008) 94-106.

DOI: 10.1016/j.compag.2007.12.004

[5] S. Jiang, W. X. Wang, D. Z. Sun, et al. Design of energy self-sufficient wireless sensor network node for orchard information acquisition, J. Transactions of the Chinese Society of Agricultural Engineering, (2012) 153-158.

[6] Y. Q. Zhang, F. Zhang, Shakhsheer Y, et al. A Batteryless 19µW MICS/ISM-Band Energy Harvesting Body Sensor Node SoC for ExG Applications, J. Solid-State Circuits, 48 (2013) 199-213.

DOI: 10.1109/jssc.2012.2221217

[7] Olgun U, Chen C C, Volakis J L. Design of an efficient ambient WiFi energy harvesting system, J. Microwaves, Antennas & Propagation, IET, 6 (2012) 1200-1206.

DOI: 10.1049/iet-map.2012.0129

[8] N. N. Li，Y. Een，H. G. Hao, et al. Analysis of the effect of foreign objects on antenna performance, J. Digital Communication, (2013) 11-13.
