Based ARMK10 Electromagnetic Sensor A/D Converter Design and Implementation

Abstract:

This paper-based design Kinetics ARM-Cortex M4 MK10DN512ZLL10 microprocessor detecting through the use of electromagnetic sensors has 10mH 100mA alternating current conductor, a continuous analog signal obtained through the solenoid to the LM358 chip amplifier many times the signal amplifier circuit , and then the analog signal is converted by the algorithm into a digital signal, and these values ​​can be obtained through a filtering process after a smooth and accurate digital microprocessor for processing.

• Periodical: Applied Mechanics and Materials (Volumes 687-691)
• Pages: 3399-3402
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.687-691.3399
• Online since: November 2014
• Authors: Chun Guang Bi*, Wei Tian Kong, Ye Ming Lu
• Keywords: A/D Converter, Filtering, K10 Microprocessor, Sampling Electromagnetic, Sensor

References

[1] Zhuo Qing, Huang Kaisheng, Shao Beibei, learn to do the smart car [M] Beijing: Beijing Aerospace Press, (2007).

[2] Peng Jun, sensor and detection technology [M], line: Xi'an University of Electronic Science and Technology Press, (2003).

[3] Freescale race committee, race car model group electromagnetic path detection reference design solutions, http: / www. smartcar. org. cn.

[4] poetry White · Analog Electronics, Beijing: Higher Education Press, (2001).

[5] Li Shibo Ma Xuzhuo Partly · hunt based magnetic field detection sensor layout of the car and electronic products World, 2009. 12. 012.

[6] Yan Shi · Digital Electronic Technology, Beijing: Higher Education Press, (1998).
