Design Optimization of Single-Phase Outer-Rotor 8S-8P Hybrid Excitation Flux Switching Motor for Electric Vehicle

Abstract:

Nowadays, in-wheel motors applied in pure electric vehicles (EVs) propulsion systems have attracted great attention in advance research and development. In-wheel direct drive provides quick torque response, higher efficiency, weight reduction, and increased vehicle space. As one of alternative, a new design of outer-rotor hybrid excitation flux switching motor (ORHEFSM) for in-wheel drive EV is proposed. In this paper, the optimization design of single-phase 8S-8P outer rotor HEFSM is analysed. Open and close circuit of initial and final design is compared based on 2-D finite element analysis (FEA). The design optimization has been made on the initial design machine shows that there is great enhancement on torque and power.

• Periodical: Applied Mechanics and Materials (Volume 695)
• Pages: 761-764
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.695.761
• Online since: November 2014
• Authors: Mohamed Mubin Aizat Mazlan*, Erwan Sulaiman, Md Zarafi Ahmad, Zhafir Aizat Husin, Hassan Ali Soomro
• Keywords: Electric Vehicle (EV), Hybrid Excitation Flux Switching Motor (HEFSM), Single-Phase Winding

References

[1] M. Z. Ahmad, E. Sulaiman, Z. A. Haron, and T. Kosaka, Impact of rotor pole number on the characteristics of outer-rotor hybrid excitation flux switching motor for in-wheel drive EV, in: Proc of Int. Conf on Electrical Eng. &Infor., UKM, 2013, pp.593-601.

DOI: 10.1016/j.protcy.2013.12.233

[2] E. Sulaiman, T. Kosaka, and N. Matsui, Design and analysis of high-power/high-torque density dual excitation switched-flux machine for traction drive in HEVs, Renewable and Sustainable Energy Reviews, 34 (2014) 517-524.

DOI: 10.1016/j.rser.2014.03.030

[3] M. Z. Ahmad, E. Sulaiman, Z. A. Haron, and T. Kosaka, Design improvement of a new outer-rotor hybrid excitation flux switching motor for in-wheel drive EV, in: IEEE Int. Power Engineering and Optimization Conference, Langkawi, 2013, pp.298-303.

DOI: 10.1109/peoco.2013.6564561

[4] W. Fei, P. Chi, K. Luk and J. S. Y. Wang, A novel outer-rotor permanent-magnet flux switching machine for urban electric vehicle propulsion, in: 3rd International Conference on Power Electronics Systems and Applications (PESA), Hong Kong, 2009, p.1.

DOI: 10.1109/iecon.2013.6700350

[5] E Sulaiman, MZ Ahmad, ZA Haron and T Kosaka, Design studies and performance of HEFSM with various slot-pole combinations for HEV applications, in: IEEE Int. Conf. on Power and Energy (PECON-2012), Sabah, 2012, pp.424-429.

DOI: 10.1109/pecon.2012.6450250

[6] Chunhua Liu, K. T. Chau, J. Z. Jiang, and Linni Jian, Design of a new outer-rotor permanent magnet hybrid machine for wind power generation, IEEE Transactions on Magnetics, 44 (2008), 1494 – 1497.

DOI: 10.1109/tmag.2007.916503

[7] M. M. A. Mazlan, E. Sulaiman and T. Kosaka, Design studies of single-phase outer-rotor hybrid excitation flux switching machine for hybrid electric vehicle, in: IEEE Int. Power Engineering and Optimization Conference, Langkawi, 2014, pp.138-143.

DOI: 10.1109/peoco.2014.6814414
