Improvement of Algorithms for Automatic Gauge Control System of the Hot-Rolling Mill

Abstract:

The paper studies issues of improvement of the automatic gauge control system (AGCS) in the continuous hot-strip train. The factors influencing longitudinal strip gauge deviations have been classified. It has been proved that Davy McKee AGCS installed at the 2,000 mill of OJSC Magnitogorsk Iron and Steel Works (OAO MMK) does not provide control accuracy factors required at the light gauge strip rolling. The paper considers the functional chart of the improved AGCS realizing algorithm of the dynamic gauge correction. Experimental studies confirm that the developed chart helps to decrease longitudinal strip gauge deviations and, hence – to improve the quality of the products.

• Periodical: Applied Mechanics and Materials (Volume 756)
• Pages: 592-597
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.756.592
• Online since: April 2015
• Authors: Alexander Sergeevich Karandaev, Vadim Rifhatovich Khramshin, Igor Yuryevich Andryushin, Andrew Grigoryevich Shubin, Boris Mikhailovich Loginov
• Keywords: Algorithm, Automatic Control System, Experimental Studies, Hot-Rolling Mill, Method, Strip Gauge

References

[1] V.M. Salganik, I.G. Gun, A.S. Karandaev and А.А. Radionov, Thin Slab Casting and Rolling Units for Steel Band Production, N.E. Bauman MSTU, Moscow, (2003).

[2] V.R. Khramshin, I. Yu. Andryushin, P.V. Shilyaev, S.A. Petryakov and A.N. Gostev, Technical Solutions of the Automatic Gauge Control System of the 2, 000 mm Hot-roll Mill, Higher School Bulletin. Electro-mechanics. 4 (2011), 41-45.

[3] V.R. Khramshin, A.S. Karandaev, S.A. Petryakov and R.R. Khramshin, Automatic Strip Gauge Control Device of the Continuous Wide-Strip Hot-Roll Mill, Russian Federation Patent No. 117839. (2012).

DOI: 10.3103/s1068371213080087

[4] V.V. Galkin, S.А. Petryakov, A.S. Karandaev and V.R. Khramshin, Automatic Correction of the Strip Head Section at the Hydraulic AGCS of the Wide-strip Hot-roll Mill, Higher School Bulletin. Electro-mechanics, 4 (2011), 46-50.

DOI: 10.3103/s1068371213080087

[5] V.R. Khramshin, A.S. Karandaev, A.A. Radionov and R.R. Khramshin, Study of Thickness Control of Strip Head Section Using Mathematical Simulation Methods, Bulletin of the South Ural State Technical University. Power Engineering Series, 13, No. 1 (2013).

[6] A.S. Karandaev, V.R. Khramshin and S.A. Petryakov, Positioning System for Automatic Strip Gauge Control of the Hot-Roll Mill, Bulletin of the G.I. Nosov Magnitogorsk State Technical University, 3 (2011), 25-29.
