The Vehicle’s Frontal Impact Influence on Driver in out of Position

Abstract:

The present paper underpins a contrastive study of the driver’s behavior and the injuries suffered in frontal vehicle collision, with a focus on the analysis of head-specific injuries. Four different simulation cases have been performed by means of the LS-DYNA software, where a seated belted and/or unbelted Hybrid III 50th percentile male dummy was in turns normally-positioned and out of position. Accordingly, both the analyses as well as the numerical simulation have been completed by applying a five-component model that encompasses: the dummy, the seat, the seatbelt, the steering wheel and the airbag. The assembly’s prescribed motion has been defined following a frontal Virtual Crash software-based impact simulation of a mid-size sedan at a velocity of 50 km/h against a rigid wall. The results analysis aimed at identifying the longitudinal variation laws over time in head displacements and accelerations as well as lateral motion. Admittedly, the results analysis certified that a more controlled-oriented approach to the selection of the driver’s normal positioning is a prerequisite in compliance with typical driving particularities.

• Periodical: Applied Mechanics and Materials (Volume 772)
• Pages: 84-89
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.772.84
• Online since: July 2015
• Authors: Oana Victoria Oțăt*, Nicolae Dumitru
• Keywords: Displacement, Frontal Impact, Head Acceleration, Out of Position

References

[1] Shaw, G., Parent, D., Purtsezov, S., Lessley, D., Crandall, J., Kent, R., Guillemot, H., Impact Response of Restrained PMHS in Frontal Sled Tests: Skeletal Deformation Patterns Under Seat Belt Loading, Stapp Car Crash Journal, vol. 53, November 2009, pp.1-48.

DOI: 10.4271/2009-22-0001

[2] Beeman, S., Kemper, A., Madigan, M., Franck, C., Loftus, S., Occupant kinematics in low-speed frontal sled tests: Human volunteers, Hybrid III ATD, and PMHS, Accident Analysis and Prevention, 2012, Elsevier.

DOI: 10.1016/j.aap.2012.01.016

[3] Daisuke Ito, Susumu Ejima, Sou Kitajima, Ryousuke Katoh, Hisao Ito, Masataka Sakane, Tomofumi Nishino, Keita Nakayama, Tadayuki Ato, Takaaki Kimura, Occupant Kinematic Behavior and Effects of a Motorized Seatbelt on Occupant Restraint of Human Volunteers during Low Speed Frontal Impact: Mini‐sled Tests with Mass Production Car Seat, IRCOBI Conference (2013).

[4] Prasad, P., Laituri, T., Sullivan, K., Estimation of AIS3+thoracic injury risks of belted drivers in NASS frontal crashes, Proceedings of the Institution of Mechanical Engineers, Part D: Journal of Automobile Engineering 2004 218: 591 DOI: 10. 1243/0954407041166067.

DOI: 10.1243/0954407041166067

[5] Orion P. Keifer, Peter D. Layson, Bradley C. Reckamp, The Effects of Seated Position on Occupant Kinematics in Low-speed Rear-end Impacts, 2005-01-1204, 2005 SAE International.

DOI: 10.4271/2005-01-1204

[6] Louden, A., Side air bag out-of-position testing of recent model year vehicles, National Highway Traffic Safety Administration United States, Paper Number: 07-213.

[7] Lund, A., Recommended procedures for evaluating occupant injury risk from deploying side airbags, Side Airbag Out-of-Position Injury Technical Working Group B-2 (Alliance, AIAM, AORC, IIHS), First revision (2003).

[8] Haufe, A., Franz, U., On the simulation of out-of-position load cases with the ale-method, Airbag 2004 - 7th International Symposium and Exhibition on Sophisticated Safety Systems. Proceedings of 7th International Symposium and Exhibition on Sophisticated Car Occupant Safety Systems - Airbag 2004 - Held Karlsruhe, Germany, 29 November-1 December (2004).

DOI: 10.1002/prep.19920170313

[9] Morris, A., Barnes, J., Fildes, B., Bentivegna, F., Seyer, K., Effectiveness of ADR 69: A Case-Control Study of Crashed Vehicles Equipped with Airbags, Department of Transport and Regional Services Australian Transport Safety Bureau, May 2001, ISBN 0 642 25544 X, ISSN1445-4467.

[10] Cameron R. Bass, Jeff R. Crandall, Walter D. Pilkey, Out-of-Position Occupant Testing (OOPS3 Series), University of Virginia, Automobile Safety Laboratory, September (1998).

[11] Directive 96/79/EC of the European Parliament and of the Council of 16 December 1996 on the protection of occupants of motor vehicles in the event of a frontal impact.
