Damage Accumulation and Fracture of Weld Joints under Low-Cyclic Loading Conditions

Abstract:

Failure of weld joints under single and cyclic pulsating loading conditions is under consideration. A weld joint is modeled by three-layer composite. Stepwise propagation of the internal I mode crack under cyclic loading is investigated. Delamination of bimaterial composed of two structured materials is considered when a crack is located at the interface between two media. Loads under pulsating loading conditions are studied for elastic-plastic material. For analysis of this process, diagrams of quasi-brittle fracture of solids under cyclic loading conditions are proposed to be used. One of curves of the proposed diagram bears resemblance to the Kitagawa-Takahashi diagram. Estimates of average dimensionless velocity of stepwise crack propagation per loading cycle have been obtained in an explicit form for plain specimens of finite width. The relations derived for the average crack growth rate can be considered as structural expressions for plotting Paris’ curves.

• Periodical: Applied Mechanics and Materials (Volume 784)
• Pages: 179-189
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.784.179
• Online since: August 2015
• Authors: V.M. Kornev*
• Keywords: Coffin Low, Damage Accumulation, Diagram of Quasi-Brittle Fracture, Fracture Criteria, Low-Cycle Loading, Paris Curves, Pre-Fracture Zone, Stress Intensity Factor (SIF), Weld Joints

References

[1] V.M. Kornev, Quasi-brittle fracture diagram of solids with structural hierarchy under low-cycle loading, Physical. Mesomech. 14 (2011), No. 5, 31-45 (in Russian).

[2] V.M. Kornev, Diagrams of quasi-brittle fatigue fracture (two-frequency loading), Physical. Mesomech. 15 (2012), No. 6, 45-58 (in Russian).

[3] V.M. Kornev, Quasi-brittle fracture diagrams under low-cycle fatigue (variable amplitude loadings), Engineering Failure Analysis. 35 (2013), P. 533-544.

DOI: 10.1016/j.engfailanal.2013.05.005

[4] M. Ya. Leonov, V.V. Pansyuk, Development of smallest cracks in a solid, Prikl. Mekh. 5 (1959), No. 4, 391-401 (in Russian).

[5] D.S. Dugdale, Yielding of steel sheets containing slits, J. Mech. Phys. Sol. 8 (1960), 100-108.

[6] H. Neuber, Kerbspannungslehre: Grunglagen fur Genaue Spannungsrechnung, Springer-Verlag, Berlin, (1937).

[7] V.V. Novozhilov, About the necessary and sufficient brittle strength criteria, Prikl. Mat. Mekh. 33 (1969), 212-222 (in Russian).

[8] V.M. Kornev, A.G. Demeshkin, Quasi-brittle fracture diagram of structured bodies in the presence of edge cracks, J. Appl. Mech. Techn. Phys. 52 (2011), No. 6, 975-985.

DOI: 10.1134/s0021894411060162

[9] V.M. Kornev, Evaluation diagram for quasi-brittle fracture of solids with structural hierarchy. Necessary and sufficient multiscale fracture criteria, Physical. Mesomech. 13 (2010), No. 1, 47-59 (in Russian).

[10] I.M. Kershtein, V.D. Klyushnikov, E.V. Lomakin, S.A. Shesterikov, Fundamental of Experimental Fracture Mechanics, Moscow universitet, Moscow, 1989 (in Russian).

[11] D. Leguillon, Strength or toughness? A criterion for crack onset at a notch, Europ. J. Mech. A/Solids, 21 (2002), 61-72.

DOI: 10.1016/s0997-7538(01)01184-6

[12] J.C. Newman, M.A. James, U. Zerbst, A review of the CTOA/CTOD fracture criterion, Engn. Fract. Mech. 70 (2003), 371-385.

DOI: 10.1016/s0013-7944(02)00125-x

[13] E.M. Castrodeza, J.E. Perez Ipina, F.L. Bastian, Fracture toughness evaluation of unidirectional fiber metal laminates using traditional CTOD () and Schwalbe () methodologies, Engn. Fract. Mech. 71 (2004), 1127-1138.

DOI: 10.1016/s0013-7944(03)00138-3

[14] V.M. Kornev, V.D. Kurguzov, N.S. Astapov, Fracture model of bimaterial under delamination of elasto-plastic structured media, Appl. Composite Mater. 20 (2013), No. 2, 129-143.

DOI: 10.1007/s10443-012-9259-6

[15] V.M. Kornev, Delamination of bimaterial and critical curves of quasi-brittle fracture in the presence of edge cracks, Advanc. Mater. Science Applic. 3 (2014), No. 4, 164-176.

DOI: 10.5963/amsa0304001

[16] M.P. Savruk, Stress Intensity Factors in Cracked Bodies, vol. 2. Fracture Mechanics and Strength of Materials, in 4 vol. Naukova Dumka, Kiev, 1988 (in Russian).

[17] Y. Murakami (ed. ), Stress Intensity Factors Handbook, in 2 vol., Pergamon Press, Oxford, (1986).

[18] H. Kitagawa, S. Takahashi, Applicability of fracture mechanics to very small cracks or the cracks in the early stages, In: Proceedings of the Second International Conference on Mechanical Behavior of Materials. Metals Park, OH: American Society for Metals, 1976, 627-631.

[19] J.J. Kruzic, R.O. Ritchie, Kitagawa-Takahashi diagrams define the limiting conditions for cyclic failure in human dentin, J. of Biomedic. Mater. Research. Part A. DOI (2006), 747-751.

DOI: 10.1002/jbm.a.30939

[20] D.C. Stouffer, J.F. Williams, A model for fatigue crack growth with a variable stress intensity factor, Engn. Fract. Mech. 11 (1979), 525-536.

DOI: 10.1016/0013-7944(79)90076-6

[21] O.N. Romaniv, S. Ya. Yarema, G.N. Nikiforchin, N.A. Makhutov, M.M. Stadnik, Fatigue and Cyclic Fracture Toughness of Structural Materials, vol. 4. Fracture Mechanics and Strength of Materials, in 4 vol. Naukova Dumka, Kiev, 1990 (in Russian).

[22] L.F. Coffin, N.Y. Schenectady, A Study of the effects of cyclic thermal stresses on a ductile metal, Trans. of the ASME. 76 (1954), No 6, 931-950.

DOI: 10.1115/1.4015021

[23] V.M. Kornev, N.S. Astapov, Fracture model of weldments under delamination, Mekhan. kompozitsionn. mater. i konstruk. 18 (2012), No. 2, 213-225 (in Russian).

[24] S.E. Kovchik, E.M. Morozov, Characteristics of transient fracture toughness of materials and methods of their determination, vol. 3. Fracture mechanics and strength of materials, in 4 vol. Naukova Dumka, Kiev, 1988 (in Russian).

[25] V.M. Kornev, Critical fracture curves and effective structure diameter for brittle and quasi-brittle materials. Physical. Mesomech. 16 (2013), No. 5, 25-34 (in Russian).
