Control System Design of 1 DOF Kinesthetic Interface

Abstract:

The aim of this work is to investigate the performance of closed-loop impedance control in the case of a kinesthetic interface, more precisely to propose this control approach even for devices in which the natural dynamics of the system are relevant. This characteristic can be found in an industrial scenario where commercial components are generally used; hence the system can't be optimized as conversely occurs in a laboratory/ research environment where custom components are generally developed. It is shown that it is possible to guarantee a high dynamic accuracy using the closed-loop impedance control with force feedback and model feedforward. Therefore this approach is suggested as a valid alternative of the most diffused admittance control. The device implemented for the tests and the obtained results are described below.

• Periodical: Applied Mechanics and Materials (Volumes 799-800)
• Pages: 1158-1165
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.799-800.1158
• Online since: October 2015
• Authors: Paolo Righettini, Alessandro Gotti, Mattia Rossetti, Roberto Strada*
• Keywords: Friction Compensation, Haptic, Impedance Control

References

[1] T.H. Massie, J.K. Salisbury, The phantom haptic interface: A device for probing virtual objects, Proc. ASME Dyn. Syst. Contr. Div., 1994 , Vol. 55 p.295–299.

[2] Information to www. novint. com.

[3] M.C. Cavusoglu, D. Feygin, F. Tendick: A critical study of the mechanical and electrical properties of the PHANToM haptic interface and improvements for high-performance control, 2002, p.555–568.

DOI: 10.1162/105474602321050695

[4] R.Q. van der Linde, P. Lammerste, E. Frederiksen,B. Ruiter: The HapticMaster, a new high-performance haptic interface, Proc. Eurohaptics Conf., 2002, p.1–5.

[5] Adams R.J., Hannaford B., Control law design for haptic interfaces to virtual reality, IEEE Trans. on Control Systems Technology, (2001).

DOI: 10.1109/87.974333

[6] T. Massie, J.K. Salisbury, The PHANTOM haptic interface: A device for probing virtual objects, Proc. ASME Winter Annual Meeting: Symposium on Haptic Interfaces for Virtual Environment and Teleoperator Systems, (1994).

DOI: 10.1109/haptic.2002.998933

[7] N. Hogan, Impedance control: An approach to manipulation, Journal of Dynamics Systems, Measurement and Control, 1980, pp.1-24.

[8] M. Bergamasco, B. Allotta, L. Bosio, L. Ferretti, G. Parrini, G.M. Prisco, F. Salsedo, G. Sartini, An Arm Exoskeleton System for Teleoperation and Virtual Environments Applications, Proc. IEEE Int. Conf. on Robotics and Automation, 1994, pp.1449-1454.

DOI: 10.1109/robot.1994.351286

[9] V. Hayward, O.R. Astley, Performance Measures for Haptic Interfaces, Robotics Research: The 7th International Symposium, Giralt, G., Hirzinger, G. (Eds. ), Springer Verlag. pp.195-207.

[10] J. Edward Colgate, P.E. Grafing, M.C. Stanley, G. Schenkel, Implementation of stiff virtual walls in force reflecting interfaces, Virtual Reality Annual International Symposium, 1993, pp.202-208.

DOI: 10.1109/vrais.1993.380777
