Trajectories Generated by a Novel Cam Driven Five-Bar Mechanism

Abstract:

In industry, the special kind of trajectory is often designed to fit the desired motion required. In literature, four-bar mechanism is popularly applied and well studied in the trajectory generation. Different types of trajectories are generated by the choose of the ratio of links. The five-bar mechanism is another popular one to generate the desired trajectory and it is more flexible due to it has two degrees of freedom. The geared five-bar mechanism is then commonly used by reducing the degree of freedom of the mechanism into one by implied one pair of gear. In this study, the trajectories generated by a novel cam driven five-bar mechanism proposed by the authors are investigated. It could supply more choices in the application of trajectory generation.

• Periodical: Applied Mechanics and Materials (Volumes 799-800)
• Pages: 685-692
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.799-800.685
• Online since: October 2015
• Authors: Shinn Liang Chang*, Dai Jia Juan, You Huang Syu
• Keywords: CAM, Geared Five-Bar Mechanism, Trajectory Generation, Vector Loop Equation

References

[1] I.I. Artobolevskii, Teoriya Mekhanizmov dlya Vosproizvedeniya Ploskikh Krivykh, Academy of Sciences of the U.S.S.R., Moscow, (1959).

[2] R.S. Hartenberg and J. Denavit, Kinematic Synthesis of Linkage, McGraw-Hill, New York, (1964).

[3] A.S. Hall, Kinematics and Linkage Design, Waveland Press, Illinois, (1986).

[4] A.G. Erdman, G.N. Sandor, and S. Kota, Mechanism Design- Analysis and Synthesis, Vol. I, 4th Ed., Prentice Hall, New Jersey, (2001).

[5] R.L. Norton, Kinematics and Dynamics of Machinery, 2nd ed., McGraw-Hill, New York, (2013).

[6] C. Zhang, R.C. Norton, and T. Hammond, Optimization of Parameters for Specified Path Generation Using an Atlas of Coupler Curves of Geared Five-Bar Linkages, Mechanism and Machine Theory, Vol. 19, No. 6, pp.459-466, (1984).

DOI: 10.1016/0094-114x(84)90052-1

[7] W.Y. Lin, Optimum Path Synthesis of a Geared Five-Bar Mechanism, Advances in Mechanical Engineering, Vol. 2013, Article ID 757935, 13 pages, (2013).

DOI: 10.1155/2013/757935

[8] D. Mundo, G. Gatti, and D.B. Dooner, Optimized Five-bar Linkage with Non-circular Gears for Exact Path Generation, Mechanism and Machine Theory, Vol. 44, pp.751-760, (2009).

DOI: 10.1016/j.mechmachtheory.2008.04.011

[9] S.L. Chang, C.B. Tsay, and L.I. Wu, Mathematical Model and Undercutting Analysis of Elliptical Gears Generated by Rack Cutters, Journal of Mechanism and Machine Theory, Vol. 31, No. 7, pp.879-890, (1996).

DOI: 10.1016/0094-114x(95)00121-e

[10] S.L. Chang and C.B. Tsay, Computerized Tooth Profile Generation and Undercut Analysis of Noncircular Gears Manufactured with Shaper Cutters, ASME Journal of Mechanical Design, Vol. 120, pp.92-99, (1998).

DOI: 10.1115/1.2826682

[11] S.L. Chang, D.H. Nguyen, Y.H. Syu, Y.H. Wang, and H.J. Huang, A Novel Five-Bar Mechanism Driven by a Cam Mechanism, 2014 International Conference on Advanced Mechatronic Systems, Kumamoto, Japan, pp. MonM01-1~5, (2014).

DOI: 10.1109/icamechs.2014.6911579

[12] L.I. Wu, Calculating Conjugate Cam Profiles by Vector Equations, Proceedings of the Institution of Mechanical Engineers, Part C, Journal of Mechanical Engineering Science, Vol. 217, No. 10, pp.1117-1123, (2003).

DOI: 10.1243/095440603322517135
