Retrofitting of STKIP ADZKIA Padang Building Using V-Inverted Steel Bracing

Abstract:

Construction failure is always associated with non-fulfillment of the quality and technical specifications of the material that should be considered when the construction process has been done. STKIP ADZKIA Padang building is one of 4-story reinforced concrete (RC) building that has structural damage during construction phase. The beams of the building undergo large deflection and the cracks appear in the wall when the building was constructed up to 2^nd floor. In this paper, building assessment was carried out to evaluate the performance of the existing building. The structure was analysed based on New Indonesian Seismic Code, SNI 03-1726-2012. The result shows that the building is not capable to resist the working loads. Furthermore, retrofitting of the building structure using V-inverted steel bracing was proposed. The analysis result shows that retrofitting of ​​the structure by installing the steel bracing on the RC frames in both X and Y directions increase the capacity of the building structure.

• Periodical: Applied Mechanics and Materials (Volume 845)
• Pages: 283-289
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.845.283
• Online since: July 2016
• Authors: Fauzan Fauzan*, Febrin Anas Ismail, Abdul Hakam, Zaidir Zaidir, Nugrafindo Yanto, Siska Apriwelni
• Keywords: Building Damage, Displacement, Retrofit, Steel Bracing

References

[1] Alinaitwe H.M., Ekolu, S. Failure of Structure in East Africa With Focus On The Causes Of Failures In The Construction Phase, Construction Materials and Structures: Proceedings of the First International Conference on Construction Materials and Structures, 2014, pp.76-85.

[2] National Standardization Agency of Indonesia, Design Standard of Earthquake Resistance for Buildings, SNI 03-1726-2002, Jakarta, Indonesia. (2002).

[3] CSI, ETABS ETABS Version 9. 7. 1, USA (2013).

[4] National Standardization Agency of Indonesia, Design Method of Earthquake Resistance for Buildings and Other Structures, SNI 03-1726-2012, Jakarta, Indonesia. (2012).

[5] National Standardization Agency of Indonesia, Procedure for the Calculation of Concrete Structure. SNI 03-2847-2002, Jakarta, Indonesia. (2002).

[6] Central Public Works Department dan Indian Building Congress, Handbook on Seismic Retrofit of Buildings. Association Indian Institute Technology. (2007).

[7] Mahmoud R. Maheri, Recent advances in seismic retrofit of RC frames, Asian Journal of Civil Engineering (Building and Housing) Vol. 6, No. 5 pp.373-391, (2005).

[8] Viswanath K. G, Prakash K.B. and Anant D., Seismic Analysis of Steel Braced Reinforced Concrete Frames, International Journal of Civil and Structural Engineering, 1, 2010, 114-122.

[9] Youssefa MA, Ghaffarzadehb H, and Nehdia M (2007). Seismic Performance of RC Frames With Concentric Internal Steel Bracing. Journal of Engineering Structures 29 (2007), pp.1561-156.

DOI: 10.1016/j.engstruct.2006.08.027

[10] Michael N. Fardis, Seismic Design, Assessment and Retrofitting of Concrete Buildings, Springer, (2009).
