Research on Rail Rolling Contact Fatigue Life of Curve Negotiation

Abstract:

Wheel/rail rolling contact fatigue is one of the most complicated and urgent problems of the key techniques of railway system, and seriously influences the operational safety. A finite element (FE) model of wheel/rail rolling contact of curve negotiation is established based on the single-layer track dynamic model, which is considering the effect of rail straightening residual stress, the actual wheel tread and the elastic support of rail track bed. The nominal stress approach is applied to study the rail rolling contact fatigue life with two residual stress-state conditions. Results show that the distribution of rolling contact fatigue life on the surface of rail head presents obvious peaks and troughs with a specific wavelength in the longitudinal direction, which are approximately corresponding to the peaks and troughs of the contact force. Meanwhile, the rail rolling contact fatigue life firstly increases and then decreases while the running speed varying from 150 to 250 km/h, and decreases while the axle load varying from 13 to 17 tonnes which do not fully show a linear law.

• Periodical: Applied Mechanics and Materials (Volume 851)
• Pages: 346-351
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.851.346
• Online since: August 2016
• Authors: Li Hua Fu, Jian Yang, Yue Zhang, Hua Song*, Wei Li
• Keywords: Curve Negotiation, Fatigue Life, Finite Element Model, Rail Rolling Contact, Wheel Rolling Contact

References

[1] X. S. Jin, Z. Y. Shen, Rolling contact fatigue of wheel/rail and its advanced research progress, J. Chin. Rail Soc. 23(2001) 92-108.

[2] Q. Xiao, The elasto-plastic analysis and fatigue damage research of wheel/rail rolling contact, China Academy of Railway Sciences, Beijing, (2012).

[3] J. J. Ding, S. L. Sun, F. Li, J. H. Huang, Simulation of coupling relationship between wheel rolling Contact fatigue and wear, Chin. J. Mech. Eng. 48 (2012) 86-90.

DOI: 10.3901/jme.2012.16.086

[4] X. Li, Z. F. Wen, X. S. Jin, Investigation into wheel wear and fatigue of heavy-haul railways, J. Chin. Rail Soc. 33 (2011) 28-34.

[5] C. G. He, G. Y. Zhou, J. Wang, G. Wen, W. J. Wang, Q. Y. Liu, Effect of curve radius of rail on rolling contact fatigue properties of wheel steel, Tribol. 34 (2014) 256-261.

[6] N. Wu, J. Zeng, Investigation into wheel-rail contact geometry relationship and wheel wear fatigue of high-speed wear fatigue of high-speed vehicle, Chin. Railway Sci. 35 (2014) 80-87.

DOI: 10.3901/jme.2013.13.183

[7] J. W. Ringsberg, Life prediction of rolling contact fatigue crack initiation, Int. J. Fatigue 23 (2001) 575-586.

DOI: 10.1016/s0142-1123(01)00024-x

[8] J. W. Ringsberg, M. Loo-Morrey, B. L. Josefson, A. Kapoor, J. H. Beynon, Prediction of fatigue crack initiation for rolling contact fatigue, Int. J. Fatigue. 22(2000) 205-215.

DOI: 10.1016/s0142-1123(99)00125-5

[9] A. Ekberg, E. Kabo, H. Andersson, An engineering model for prediction of rolling contact fatigue of railway wheels, Fatig. Fract. Eng. Mater. Struct. 5 (2002) 899-909.

DOI: 10.1046/j.1460-2695.2002.00535.x

[10] C. Richard Liu, Y. Choi, Rolling contact fatigue life model incorporating residual stress scatter, Int. J. Mech. Sci. 50 (2008) 1572-1577.

DOI: 10.1016/j.ijmecsci.2008.10.008

[11] M. Taraf, E. H. Zahaf, O. Oussouaddi, A. Zeghloul, Numerical analysis for predicting the rolling contact Fatigue crack initiation in a railway wheel steel, Tribol. Int. 43(2009) 585-593.

DOI: 10.1016/j.triboint.2009.09.007

[12] M. Šraml, J. FlašKER, I. Potrč, Numerical procedure for predicting the rolling contact fatigue crack initiation, Int. J. Fatigue, 25 (2003) 585-595.

DOI: 10.1016/s0142-1123(03)00019-7

[13] F. J. Franklin, I. Widiyarta, A. Kapoor, Computer simulation of wear and rolling contact fatigue, Wear, 251 (2001) 949-955.

DOI: 10.1016/s0043-1648(01)00732-3

[14] W. M. Zhai, Vehicle-Track Coupling Dynamics, third ed., Science Press, Beijing, (2007).

[15] L. Liu, The study on the fatigue crack initiation and propagation life prediction of rail, Southwest Jiaotong University, Chengdu, (2008).

[16] S. H. Tong, The numerical simulation for hot-preflex heavy rail straightening, University of Science and Technology Liaoning, Anshan, (2012).

[17] H. Song, J. Yang, L. B. Song, K. X. Li, W. Li, Research on the variation of residual stress in the rail caused by the wheels repeated rolling, Key Eng. Mat. 665 (2016) 213-216.

DOI: 10.4028/www.scientific.net/kem.665.213
