Design and Fabrication of Volume Holographic Gratings with Large Angular Bandwidth and High Diffraction Efficiency

Abstract:

High-performance volume holographic grating (VHG) is an important coupling element for a holographic waveguide system. Small angular bandwidth and low diffraction efficiency restrict the applications of VHGs. Based on asymmetrical recording, a reflection VHG with large angular bandwidth and high diffraction efficiency are designed and prepared. The relationship between the recording angles and the diffraction efficiency is discussed first and several combinations of the recording angles are found. Then the relationship between the recording angles and the angular bandwidth is further analyzed, which could obtain the optimal recording setup. The experimental results show that when the incident angle of the reference light and signal light is 10° and 59°, the angular bandwidth of the fabricated VHG reaches 25° and the diffraction efficiency is 90%. However, the wavelength shift happens. The recording angle is modified to improve wavelength shift. The method proposed in this paper could help design a VHG with large angular bandwidth and high diffraction efficiency.

• Periodical: Applied Mechanics and Materials (Volume 926)
• Pages: 51-57
• DOI: https://doi.org/10.4028/p-N2Y8o4
• Online since: April 2025
• Authors: Qi Bin Feng*, Yu Song Guo, Guo Qiang Lv
• Keywords: Angular Bandwidth, Diffraction Efficiency, Recording Angle, Volume Holographic Grating

References

[1] Chenliang Chang, Kiseung Bang, Gordon Wetzstein, Byoungho Lee, and Liang Gao. "Toward the next-generation VR/AR optics: a review of holographic near-eye displays from a human-centric perspective," Optica, 7(11): 1563-1578 (2020).

DOI: 10.1364/optica.406004

[2] Maimone A, Georgiou A, Kollin J S. "Holographic near-eye displays for virtual and augmented reality," ACM Transactions on Graphics, 36(4): 1-16 (2017).

DOI: 10.1145/3072959.3073624

[3] Wu Z, Liu J, Wang Y. "A high-efficiency holographic waveguide display system with a prism in-coupler," Journal of the Society for Information Display, 21(12): 524-528 (2013).

DOI: 10.1002/jsid.204

[4] Cao C, Liao S, Liao Z Y, et al. "Design of large field off-axis reflection optical system based on free-form surface," Acta Optica Sinica, 40(8): 0808001-0808007 (2020).

[5] Zheng Z Z, Yang Z, Xiu L C, et al. "Development and application of high diffraction efficiency short-wave infrared convex shining grating," Acta Optica Sinica, 40(12): 1205002-1205010 (2020).

DOI: 10.3788/aos202040.1205002

[6] Amitai Y, Friesem A A, Weiss V. "Holographic elements with high efficiency and low aberrations for helmet displays," Applied Optics, 28(16): 3405-3416 (1989).

DOI: 10.1364/ao.28.003405

[7] Murakami E, Oguro Y, Sakamoto Y. "Study on compact head-mounted display system using electro-holography for augmented reality," IEICE Transactions on Electronics, 100(11): 965-971 (2017).

DOI: 10.1587/transele.e100.c.965

[8] Duan X, Liu J, Shi X, Zhang Z, J. "Full-color see-through near-eye holographic display with 80° field of view and an expanded eye-box," Optics Express, 28(21): 31316-31329 (2020).

DOI: 10.1364/oe.399359

[9] Shi R, Liu J, Zhao H, et al. "Chromatic dispersion correction in planar waveguide using one-layer volume holograms based on three-step exposure," Applied Optics, 51(20):4703-4708 (2012).

DOI: 10.1364/ao.51.004703

[10] Han J, Liu J, Yao X, et al. "Portable waveguide display system with a large field of view by integrating freeform elements and volume holograms," Optics Express, 23(3): 3534-3549 (2015).

DOI: 10.1364/oe.23.003534

[11] Mukawa H, Akutsu K, Matsumura I, et al. "A full-color eyewear display using planar waveguides with reflection volume holograms," Journal of the Society for Information Display, 17(3): 185-193 (2009).

DOI: 10.1889/jsid17.3.185

[12] Yu L L. "Preparation of reflective volume Holographic grating," Dissertation of Southeast University Nanjing (2017).

[13] Lin W K, Matoba O, Lin B S, Su W C. "Astigmatism and deformation correction for a holographic head-mounted display with a wedge-shaped holographic waveguide," Applied optics, 57(25): 7094-7101(2018).

DOI: 10.1364/ao.57.007094

[14] Piao M L, Kim N. "Achieving high levels of color uniformity and optical efficiency for a wedge-shaped waveguide head-mounted display using a photopolymer," Applied Optics, 53(10): 2180-2186 (2014).

DOI: 10.1364/ao.53.002180

[15] Guo J, Tu Y, Yang L, et al. "Holographic waveguide display with a combined- grating in-coupler," Applied Optics, 55(32): 9293-9298 (2016).

DOI: 10.1364/ao.55.009293
