The Design of Plate Mills Hydraulic Lubricating and Monitoring System

Abstract:

Plate mills hydraulic system is made up of several hydraulic stations, lubrication stations and grease stations, these hydraulic stations and lubrication stations are distributed around the mills. Each hydraulic station possesses qualities of successive long working time, high reliability and signal complexity, and it can satisfy diverse demands of high grade pressure or temperature control, etc. This paper is based on these demands, assembling control missions of hydraulic and lubricating stations. Several PLC S7-300 were chosen to match the need of controlling mills hydraulic and lubricating system for a certain plate factory, and the HMI monitoring system for mill hydraulic and lubricating stations was developed by WINCC, which achieved central control and monitoring the hydraulic and lubricating system of plate mills.

• Periodical: Advanced Materials Research (Volumes 1006-1007)
• Pages: 643-649
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1006-1007.643
• Online since: August 2014
• Authors: Zhi Qiang Wu, Jun Fang Zhao
• Keywords: HMI, Hydraulic System, PLC
