The Finite Element Analysis for Ultra-Precision Single-Plane Lapping Machine Bed

Abstract:

There are four kinds of ultra-precision lapping machine bed were developed: with/without reinforcing rib, with/without a pair of closed sides. The finite element analysis was used to find the optimal design of the machine bed. The 3D model of the ultra-precision lapping machine bed was built by SolidWorks, and ANSYS software was used for static analysis and modal analysis. The results suggest that when reinforcing rib and a pair of closed sides were owned, the machine bed had some better static and dynamic characteristics. The mix-deformation of this machine bed was 1.911μm, and the first-order inherent frequency was 101.74Hz.

• Periodical: Advanced Materials Research (Volume 1027)
• Pages: 63-67
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1027.63
• Online since: October 2014
• Authors: Sheng Lan Li, Cheng Yong Wang*, Qing Jian Li, Yue Xian Song, Xu Xiong
• Keywords: Model Analysis, Single-Plane Lapping Machine Bed, Structure Analysis, Total Deformation

References

[1] Y.Z. Tao, et al.: Diamond and Abrasives Engineering Vol. 172(4) (2009). pp.34-38(In Chinese).

[2] L. Zhang, et al.: Applied Mechanics and Materials Vol. 159 (2012). pp.156-159.

[3] L. Weng, et al.: AVIATION PRECISION MANUFACTURING TECHNOLOGY Vol. 44(3) (2008). pp.10-14(In Chinese).

[4] Ship-Peng Lo, et al.: Journal of Materials Processing Technology Vol. 168 (2005). pp.250-257.

[5] W. Yang, et al.: Advance Materials Research Vols. 399-401 (2012). pp.1731-1735.

[6] S.S. Rao, Mechanical Vibrations, Addison Wesley Publishing, (1995).
