Photoelectrochemical Properties of Anatase TiO₂ Films Prepared by Improved Liquid Phase Deposition

Abstract:

In this paper, the hydrothermal-assisted liquid phase deposition (HT-LPD) method has been developed to prepare TiO₂ films. The crystalline structures and morphologies of as-prepared TiO₂ films were analyzed using an X-ray diffractometer (XRD) and scanning electron microscope (SEM). It was found that the HT-LPD TiO₂ film showed good crystallinity with preferrred orientation along c-axis. Moreover, the as-prepared TiO₂ films consisted of two layers, with the tiny nanoparticles as the underlying layer and the flower-like clusters as the upper layer. The photoelectrochemical measurements revealed that, when illuminated by the white light, the HT-LPD TiO₂ films exhibited a more negative photopotential value and an increased photocurrent value with elevated reaction temperature, excepting for the sample prerared at 150 °C. In summary, the TiO₂ films prepared by the improved LPD method could be served as the promising photoanode for the photoelectrochemical applications.

You might also be interested in these eBooks

Contemporary Approaches in Material Science and Materials Processing Technologies

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 1120-1121)

Pages:

419-423

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.1120-1121.419

Citation:

Cite this paper

Online since:

July 2015

Authors:

Cai Xia Lei, X.L. Jiang, Y. Liu, X. Liu, Y.T. Ma, S. Yang, S.Z. Qin, G.S. Zhang, Z.D. Feng

Keywords:

Liquid Phase Deposition, Photoelctrochemical Properties, TiO2 Films

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] A. Fujishima, K. Honda, Electrochemical photolysis of water at a semiconductor electrode, Nature 238 (1972) 37-38.

DOI: 10.1038/238037a0

Google Scholar

[2] J. Schneider, M. Matsuoka, M. Takeuchi, J. Zhang, Y. Horiuchi, M. Anpo, D.W. Bahnemann, Understanding TiO2 photocatalysis: mechanisms and materials, Chem. Rev. 114 (2014) 9919-9986.

DOI: 10.1021/cr5001892

Google Scholar

[3] C.X. Lei, H. Zhou, Z.D. Feng, Visible-light-driven photogenerated cathodic protection of stainless steel by liquid-phase-deposited TiO2 films, Electrochim. Acta 68 (2012) 134-140.

DOI: 10.1016/j.electacta.2012.02.052

Google Scholar

[4] S.K. Park, J.S. Jeong, T.K. Yun, J.Y. Bae, Preparation of carbon-doped TiO2 and its application as a photoelectrodes in dye-sensitized solar cells, J. Nanosci. Nanotechnol. 15 (2015) 1529-1532.

DOI: 10.1166/jnn.2015.9338

Google Scholar

[5] S. Murgolo, F. Petronella, R. Ciannarella, R. Comparelli, A. Agostiano, M.L. Curri, G. Mascolo, UV and solar-based photocatalytic degradation of organic pollutants by nano-sized TiO2 grown on carbon nanotubes, Catal. Today 240 (2015) 114-124.

DOI: 10.1016/j.cattod.2014.04.021

Google Scholar

[6] Y. Amao, A. Tadokoro, M. Nakamura, N. Shuto, A. Kuroki, Artificial photosynthesis by using chloroplasts from spinach adsorbed on a nanocrystalline TiO2 electrode for photovoltaic conversion, Res. Chem. Intermediat. 40 (2015) 3257-3265.

DOI: 10.1007/s11164-014-1831-2

Google Scholar

[7] S.R. Meher, L. Balakrishnan, Sol-gel derived nanocrystalline TiO2 thin films: a promising candidate for self-cleaning smart window applications, Mater. Sci. Semicond. Process. 26 (2014) 251-258.

DOI: 10.1016/j.mssp.2014.05.006

Google Scholar

[8] T.D. Dongale, S.S. Shinde, R.K. Kamat, K.Y. Rajpure, Nanostructured TiO2 thin film memristor using hydrothermal process, J. Alloys Compd. 593 (2014) 267-270.

DOI: 10.1016/j.jallcom.2014.01.093

Google Scholar

[9] N. Ohtsu, H. Kanno, S. Komiya, Y. Mizukoshi, N. Masahashi, Fabrication of visible-light-responsive titanium dioxide layer on titanium using anodic oxidization in nitric acid, Appl. Surf. Sci. 270 (2013) 513-518.

DOI: 10.1016/j.apsusc.2013.01.071

Google Scholar

[10] H. Parikh, M.R. De Guire, Recent progress in the synthesis of oxide films from liquid solutions, J. Ceram. Soc. Jpn. 117 (2009) 228-235.

DOI: 10.2109/jcersj2.117.228

Google Scholar

[11] C.X. Lei, H. Zhou, Z.D. Feng, Effect of liquid-phase-deposited parameters on the photogenerated cathodic protection properties of TiO2 films, J. Alloys. Compd. 542 (2012) 164-169.

DOI: 10.1016/j.jallcom.2012.07.078

Google Scholar

[12] C.X. Lei, H. Zhou, Z.D. Feng, Y.F. Zhu, R.G. Du, Low-temperature liquid phase deposited TiO2 films on stainless steel for photogenerated cathodic protection applications, Appl. Surf. Sci. 257 (2011) 7330-7334.

DOI: 10.1016/j.apsusc.2011.03.122

Google Scholar

[13] N. Wang, C. Zhang, H. He, X. Li, J. Yang, Hydrothermal-assisted liquid phase deposition synthesis and photocatalytic activities of titania nanocrystals, Powder Technol. 205 (2011) 61-64.

DOI: 10.1016/j.powtec.2010.08.064

Google Scholar
