The Effect of Electropolishing Time Variation at Room Temperature and Low Voltage on the Surface Quality of Cardiovascular Stent

Abstract:

Electropolishing is an attractive method for surface smoothing of cardiovascular stent. This study investigated the effect of times of electropolishing on the surface characteristics both are upper surface and surface of the strut of cardiovascular stent after the by die sinking electrical discharge machining (EDM). The observed surface characteristics of the strut were recast layer, surface roughness and brightness. The weight analysis, and the reduction of the width strut were conducted. The recast layer was analyzed by optical microscope qualitatively, the surface roughness was measured by surface texture measuring instrument, the weight analysis and the reduction of width strut were calculated. The stent was made from steel AISI 316 L. The times which were used in the electropolishing were 3 minutes, 7 minutes, and 11 minutes. The experimental results show that the time for smoothing and brightening of stent at room temperature and low voltage 5 V is 7 minutes. The times affect the upper and EDM surface roughness, the weight of stent and the width of strut. The results show that increasing of times, than the value of surface roughness, the weight of stent and the width of strut will decrease, and vice versa. The average surface roughness of EDM surface after electropolishing is in the range of 3.49 – 1.62 µm. The average surface roughness of upper surface after electropolishing is in the range of 0.55-0.22 µm. The weight analysis show that the loss of weight is in the range of 0.12-1.12 %, and the reduction of width strut is in the range of 11.02 – 69.3 %.

• Periodical: Advanced Materials Research (Volume 1154)
• Pages: 91-101
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1154.91
• Online since: June 2019
• Authors: E. Pujiyulianto*, Suyitno Suyitno
• Keywords: Austenitic Stainless Steel, Cardiovascular Stent, Electrical Discharge Machining (EDM), Electropolishing, Surface Roughness

References

[1] (14th june 1993). Council Directive 93/42/EEC. Conc. Med. Devic.

[2] D. Suryawan, Desain, Pemodelan, dan Pembuatan Prototype Stent Jantung Menggunakan Electrical Discharge Machining (EDM), Master Thesis, UGM, Yogyakarta, Indonesia (2017).

[3] H. Hermawan and D. Mantovani, Process of prototyping Coronary Stent from Biodegradable Fe-Mn Alloys. Acta Biomat. , 9 (10) (2013), 8585-8592.

DOI: 10.1016/j.actbio.2013.04.027

[4] A. Bhuyan, B. Gregory, H. Lei, S. Y. Yee, and Y. B. Gianchandani, Pulse and DC electropolishing of stainless steel for stents and other devices. Proc. of IEEE Sens.4th IEEE Conf. on Sens. (2005) 314-317.

DOI: 10.1109/icsens.2005.1597699

[5] A. Raval, A. Choubey, C. Engineer and D. Kothwala, Surface Conditioning of 316LVM Slotted Tube Cardiovascular Stents. J. of Biomat. App. 19 (3) (2005), 197-213.

DOI: 10.1177/0885328205046564

[6] A. Mazinani, Surface Modification Treatment of cardiovascular Stent. Milan: Department of Chemistry, Materials and Chemical Engineering, Politecnico Di Milano (2014).

[7] P. Sojitra, C. Engineer, D. Kothwala, A. Raval, H. Kotadia, and G. Mehta, Electropolishing of 316 LVM Stainless Steel Cardiovascular Stent : An Investigation of Material Removal, Surface Roughness and Corrosion Behaviour. Tren. Biomet., 23 (3) (2010), 115-121.

[8] P. A. Jacquet, The anodic behavior of cooper in aqueous solutions of orthoposphric acid. Trans. of the Electr. Soc, 69 (1936), 629.

[9] B. Chatterjee, Science and Industry of Electropolishing. Jahrbuch Oberflachentechnik Band. (2015).

[10] C. M. Brett, and A. M. Brett, Electrochemistry : Principles, Methodes, and Applications. New York : USA: Oxford University Press (1994).

[11] J. Koryta, J. Dvorak, and L. Kavan, Principles of Electrochemistry : Second Edition. New York : USA: John Wiley & Sons (1993).

[12] F. Nazneem, P. Galvin, D. W. Arrigan, M. Thompson, P. Benvenuto, and G. Herzog, Electropolishing of medical-grade stainless steel in preparation for surface nano-texturing. J. of Sol. State. Elec. 16 (4) (2012), 1389-1397.

DOI: 10.1007/s10008-011-1539-9
