The Investigation on Small Hole Drilling-Grinding in Glass and Ceramic

Abstract:

Making holes in glass or ceramic with conventional twist drills is difficult because of the hard and brittle properties of the workpieces, but the drilling-grinding process with diamond core-tools has found application in the field due to its high efficiency and low cost. However, small hole drilling-grinding with the core tools is still a challenge because the small core tools have a limited strength and chip-removal capacity. In this paper, the small hole drilling-grinding in glass and ceramic by diamond core-tools with 4mm diameter is experimentally investigated, the drilling-grinding force and heat are measured and calculated, the performances of two types of electroplating diamond core tools are compared.

• Periodical: Advanced Materials Research (Volumes 126-128)
• Pages: 258-262
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.126-128.258
• Online since: August 2010
• Authors: Yan Ming Quan, Jia Jia Chen, Hao Xu
• Keywords: Ceramic, Drilling-Grinding, Electroplating Diamond, Glass, Processing Heat

References

[1] K. Ishikawa, H. Suwabe, T. Nishide et al: A study on combined vibration drilling by ultrasonic and low-frequency vibrations for hard and brittle materials. Precision Engineering, 1998, 22: 196-205.

DOI: 10.1016/s0141-6359(98)00014-2

[2] X. L. Jin, J. T. Yuan: Experimental Study on Drilling Technology for Engineering Ceramics. Tool technology, 2004, 38: 22-24 (in Chinese).

[3] J. P. Choi, B.H. Jeon and B.H. Kim: Chemical-assisted ultrasonic machining of glass. Journal of Materials Processing Technology, 2007, 191: 153-156.

DOI: 10.1016/j.jmatprotec.2007.03.017

[4] K.P. Rajurkar, Z.Y. Wang, A. Kuppattan: Micro removal of ceramics material(Al2O3) in the precision ultrasonic machining. Precision Engineering, 1999, 23: 73~78.

DOI: 10.1016/s0141-6359(98)00026-9

[5] P.L. Guzzo, A.A. Raslan: Ultrasonic abrasion of quartz crystals. Wear, 2003, 255: 67~77.

DOI: 10.1016/s0043-1648(03)00094-2

[6] H.J. Booth. Recent applications of pulsed lasers in advanced materials processing. Thin Solid Films, 2004, 453-454: 450~457.

DOI: 10.1016/j.tsf.2003.11.130

[7] D.A. Gorham, A.D. Salman: Indentation fracture of glass and mechanisms of material removal. Wear, 1999, 233: 151-156.

DOI: 10.1016/s0043-1648(99)00179-9

[8] A.B. Yu, L.J. Ma, Y.F. Tan: Tool wear characteristics during drilling processes of fluorophlogopite glass ceramic. Tribology. 2006, 26: 80-83.

[9] C.C. Tsao, H. Hocheng: Effects of peripheral drilling moment on delamination using special drill bits. Journal of Materials Processing Technology, 2008,. 201: 471-470.

DOI: 10.1016/j.jmatprotec.2007.11.225

[10] J. Mathew, N. Ramakrishnan and N.K. Naik: Investigations into the effect of geometry of a trepanning tool on thrust and torque during drilling of GFRP composites. Journal of Materials Processing Technology, 1999, 91: 1-11.

DOI: 10.1016/s0924-0136(98)00416-6

[11] Y.M. Quan, L. Liang, W.W. Zhong: The experimental research on small hole machining in glass using diamond abrasive core-tools. Advanced Materials Research, 2009, 76- 78: 491-496.

DOI: 10.4028/www.scientific.net/amr.76-78.491
