Research on Fault Diagnosis of Ship Stern Bearing Based on Vibration Analysis

Abstract:

The application of vibration analysis in fault diagnosis of rotary machine becomes more and more popular. Aiming at an abnormal high frequency vibration of a stern bearing, this paper proposed a method of fault diagnosis based on the analysis of vibration characteristics and the spectral analysis. From the gathered vibration data of a stern shaft bench through Pulse Vibration Analysis Platform, using the speed spectrum array to determine the characteristics of vibration source, with the analysis of vibration characteristics of the bench, it concluded that the abnormal high frequency vibration source of the stern bearing is a weak rigidity part of bench─ tacho-torque meter. The vibration data of again test after strengthening the part illustrated the validity of this diagnostic mode.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 2354-2358
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.2354
• Online since: October 2010
• Authors: Yong Jin, Lin Liu Zheng
• Keywords: Pulse, Speed Spectrum Array, Stern Bearing, Vibration Analysis (VA)

References

[1] H. Li, H.Q. Zhen and L.W. Tang: Journal of Data Acquisition &Processing, Vol. 21 (2006) No. 4, pp, 454-459. (In Chinese).

[2] S.C. Du: Journal of Vibration Engineering, Vol. 17 (2004) No. S, pp, 450-455. (In Chinese).

[3] C.J. Yang: Journal of Logistical Engineering University, 2006, No. 2, pp, 54-57. (In Chinese).

[4] B. Yuan: Journal of Hunan Metallurgical Professional Technology College, Vol. 6 (2006) No. 3, pp, 407-409. (In Chinese).

[5] J.J. Zhang, J.R. He and L. Yang: Gas Turbine Experiment and Research, Vol. 20 (2007) No. 1, pp, 44-51. (In Chinese).
