Modal Analysis of Ring-Plate of Double Crank Four Ring-Plate-Type Cycloid Reducer

Abstract:

The vibration tests of the double crank ring-plate-type cycloid reducer driven by three gears are tested and analyzed with the HEAD acoustics multi-channel vibration test and analysis system. The tests of the reducer are completed under the condition of different rotational speeds and different loads. The vibration distribution rules of the reducer are obtained. The three dimensional model of the ring-plates of the double crank four ring-plate-type cycloid reducer with Pro/E are established, the modality analysis are carried out on the model by the use of ANSYS. The natural frequencies and the corresponding vibration models of the ring-plates are gained. The results are well consistent with that of the vibration tests which provide the basis for further study of vibration and noise reduction.

You might also be interested in these eBooks

Manufacturing Engineering and Automation I

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 139-141)

Pages:

2364-2367

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.139-141.2364

Citation:

Cite this paper

Online since:

October 2010

Authors:

Bing Yang, Wen Liu, Yan Liu

Keywords:

Modal Analysis, Natural Frequency, Reducer

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] W.D. He and X. Li: Study on double crank ring-plate-type cycloid drive. Chinese Journal of Mechanical Engineering, 36(5): 84-88. (2000).

Google Scholar

[2] L.X. Li and X. Li: Experimental study of double crank ring-plate-type pin-cycloidal gear planetary drive. Journal of Dalian Railway Institute, 26(1): 1-4. (2005).

DOI: 10.3901/cjme.2003.03.252

Google Scholar

[3] X. Li and W. D. He: A new cycloid drive with high-load capacity and high efficiency. ASME Journal of Mechanical Design, 126(4): 683-686. (2004).

DOI: 10.1115/1.1758254

Google Scholar

[4] J.H. Bao and W.D. He: Finite element analysis of cylinder block of crank ring-plate cycloid reducer. Journal of Dalian Railway Institute, 26(1): 38-40. (2005).

Google Scholar
